| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE1001 | STRIP, SLIPPER | 20 | ||||
| ? | 58E-06-03070 | COIL, ROTOR | 8 | ||||
| ? | VE4643 | CLAMP, SUPPORT | 4 | ||||
| ? | XA4156 | COLLECTOR RING ASSEMBLY | 1 | ||||
| ? | VJ1063 | STRAP, CONNECTION | 7 | ||||
| ? | BF4833 | STRIP, BRAZING | 16 | ||||
| ? | VE7006 | CORE, ROTOR | 1 | ||||
| ? | GE1084 | SHAFT, ROTOR | 1 | ||||
| ? | BF3105 | RING, TIE | 1 | ||||
| ? | BF1007 | TAPE, GLASS | |||||
| ? | (ALSO SEE FIGURE 43866 FOR BALANCE OF | ||||||
| ? | ROTOR ASSEMBLY COMPONENT PARTS.) |
