| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-43-10120 | GUIDE, CARD | 14 | ||||
| ? | 58E-43-00410 | MODULE ASSEMBLY | 1 | ||||
| ? | 58E-43-10291 | TMC CPU CARD (190F) | 2 | ||||
| ? | 58E-43-10300 | DUAL ETHERNET SWITCH CARD (191F) | 1 | ||||
| ? | 58E-43-10281 | ANALOG INPUT CARD (173F) | 1 | ||||
| ? | 58E-43-10270 | DIGITAL I/O INPUT CARD (104F) | 2 | ||||
| ? | 58E-43-10261 | CPU CARD (187F) | 1 | ||||
| ? | 58E-43-10150 | BACKPLANE | 1 | ||||
| ? | 58E-43-00400 | MODULE ASSEMBLY | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | GE0611 | TIE, HOOK-AND-LOOP | |||||
| ? | 58E-43-00500 | HARNESS, WIRING - FIBER OPTIC (568') (1) | 1 | ||||
| ? | GE0470 | KIT, FIBER OPTIC REPAIR (2) | 1 | ||||
| ? | XA5143 | • CONNECTOR, GRAY | 5 | ||||
| ? | XA5144 | • CONNECTOR, BLUE | 5 | ||||
| ? | • WIRE MARKER | 10 | |||||
| ? | XA5141 | • KIT, CABLE FINISHING | 1 | ||||
| ? | • • FIBER OPTIC CABLE (50') | 1 | |||||
| ? | • • SANDPAPER | 8 | |||||
| ? | • • POLISHING PAPER | 8 | |||||
| ? | NOTE: (1) GE0470 OR GE0654 TOOL KIT NECESSARY TO | ||||||
| ? | SERVICE FIBER OPTIC CABLE. | ||||||
| ? | (2) GE0654 FIBER OPTIC REPAIR KIT WITH CRIMPER | ||||||
| ? | TOOL IS ALSO AVAILABLE. |
