Каталог Komatsu

k-part

Номер на схеме	Каталожный номер	Название	Количество
?	MM0358	MACHINE SCREW - M6 X 1.00 X 16	2
?	MM0469	LOCKWASHER - M6	2
?	MM0459	FLAT WASHER - M6	2
?	VA2826	COVER, SWITCH	1
?	VN7129	MACHINE SCREW - #6 - 32NC X 5/8"	6
?	DF4944	LOCKWASHER - #6	6
?	VN9764	FLAT WASHER - #6	6
?	PB9072	CONDULET, SINGLE GANG	1
?	EM9705	HANDRAIL	2
?	58E-06-04790	HARNESS, WIRING - PUMP MODULE LIGHT	1
?	WB3097	CLAMP, CUSHIONED - 1/2"	5
?	MM0178	NUT - M10 X 1.50	7
?	MM0471	LOCKWASHER - M10	13
?	MM0461	FLAT WASHER - M10	2
?	58D-06-10660	LIGHT, HALOGEN	1
?	PC2621	SWIVEL, LEVELING	2
?	EM8225	PLATFORM	1
?	MM0606	CAPSCREW - M10 X 1.50 X 30	10
?	MM0713	FLAT WASHER, HARDENED - M10	15
?	EM8558	DISC, RETAINING	1
?	MM0719	NUT - M10 X 1.50	2
?	TY8375	SPACER	1
?	SG3146	GROMMET	1
?	MM0611	CAPSCREW - M10 X 1.50 X 60	1
?	EM1393	SPACER	1
?	MM0601	CAPSCREW - M8 X 1.25 X 70	1
?	MM0692	LOCKNUT - M8 X 1.25	1
?	EL7725	LADDER	1
?	MM0618	CAPSCREW - M12 X 1.75 X 30	4
?	MM0472	LOCKWASHER - M12	4
?	MM0714	FLAT WASHER, HARDENED - M12	4
?	VZ2926	GRIP, CORD	1
?	VA2828	SWITCH, FLUSH	1
?	MM0470	LOCKWASHER - M8	1
?	MM0712	FLAT WASHER, HARDENED - M8	1
