| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-06-12210 | KOMVISION DISPLAY - PANEL | 1 | ||||
| ? | 58E-06-12220 | • PLATE, ARCS PANEL | 1 | ||||
| ? | 58E-06-12390 | • SWITCH, MOMENTARY - DISPLAY IMAGE LOCK | 1 | ||||
| ? | 58E-06-12370 | • SWITCH, MOMENTARY - DIAGONAL ARROW | 1 | ||||
| ? | 58E-06-12410 | • INDICATOR, POWER STATUS | 1 | ||||
| ? | 58E-06-12240 | • HARNESS, WIRING - ARCS PANEL | 1 | ||||
| ? | 58E-06-12380 | • SWITCH, MOMENTARY - DISPLAY BRIGHTER | 1 | ||||
| ? | 58E-06-12340 | • SWITCH, MOMENTARY - DISPLAY DIMMER | 1 | ||||
| ? | 58E-06-12330 | • SWITCH, MOMENTARY - DIAGONAL ARROW | 1 | ||||
| ? | 58E-06-12290 | • SWITCH, MOMENTARY - WARNING CANCEL | 1 | ||||
| ? | 58E-06-12280 | • SWITCH, MOMENTARY - BODY DISPLAY ON/OFF | 1 | ||||
| ? | 58E-06-12270 | • SWITCH MOMENTARY - GRIDLINE DISPLAY | 1 | ||||
| ? | 58E-06-12260 | • SWITCH MOMENTARY - DISPLAY MODE | 1 | ||||
| ? | 58E-06-12310 | • SWITCH MOMENTARY - UP/DOWN ARROW | 1 | ||||
| ? | 58E-06-12420 | • SWITCH MOMENTARY - INDICATOR CHASSIS | 1 | ||||
| ? | 58E-06-12320 | • SWITCH MOMENTARY - DIAGONAL ARROW | 1 | ||||
| ? | 58E-06-12350 | • SWITCH MOMENTARY - DIAGONAL ARROW | 1 | ||||
| ? | 58E-06-12360 | • SWITCH MOMENTARY - UP/DOWN ARROW | 1 | ||||
| ? | 58E-06-12230 | • CARD, PCB ASSEMBLY | 1 | ||||
| ? | 58E-06-12430 | • WASHER | 4 | ||||
| ? | 58E-06-12440 | • NUT, STAND OFF | 4 | ||||
| ? | 58E-06-12250 | • NUT | 4 | ||||
| ? | 7831-47-9300 | MONITOR | 1 | ||||
| ? | MM0019 | CAPSCREW - M6 X 1.00 X 16 | 4 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 4 |
