| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB5066 | PANEL | 1 | ||||
| ? | VE4649 | PANEL BASE | 1 | ||||
| ? | VE4379 | RESISTOR ASSEMBLY | 3 | ||||
| ? | VE2705 | CHANNEL | 6 | ||||
| ? | VE0066 | RESISTOR - 200 WATT, 25 OHM | 6 | ||||
| ? | VE1959 | BUSHING, INSULATOR | 12 | ||||
| ? | VE2707 | MACHINE SCREW - #8 - 36NF X 12" | 6 | ||||
| ? | VE4607 | NUT | 12 | ||||
| ? | VE4604 | FLAT WASHER | 24 | ||||
| ? | VE4606 | LOCKWASHER - #8 | 12 | ||||
| ? | VE2783 | CONTACT POST / STUDS | 3 | ||||
| ? | C5746 | CAPSCREW - 1/4" - 20NC X 3/4" | 3 | ||||
| ? | VE7202 | FLAT WASHER - 1/4" | 3 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | 3 | ||||
| ? | VE4652 | CABLE ASSEMBLY | 3 | ||||
| ? | VE4653 | MACHINE SCREW - #8 - 36NF X 1/2" | 6 | ||||
| ? | VE3846 | CAPACITOR ASSEMBLY | 3 | ||||
| ? | VE0784 | CLAMP, CAPACITOR | 6 | ||||
| ? | VE4653 | MACHINE SCREW - #8 - 36NF X 1/2" | 12 | ||||
| ? | VE4606 | LOCKWASHER - #8 | 12 | ||||
| ? | VE4654 | MACHINE SCREW - #10 - 32NF X 3/4" | 6 | ||||
| ? | VE4655 | FLAT WASHER - #10 | 6 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 9 | ||||
| ? | VE4604 | FLAT WASHER | 12 | ||||
| ? | VE4607 | NUT | 6 | ||||
| ? | SF2755 | NUT | 3 | ||||
| ? | VS6817 | GROMMET, RUBBER | 1 | ||||
| ? | VE4656 | CABLE | 2 | ||||
| ? | VE4657 | CABLE | 1 | ||||
| ? | VE4658 | FLAT WASHER - #10 | 3 |
