| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EL6085 | LADDER, DIAGONAL | 1 | ||||
| ? | EG0868 | STEP | 1 | ||||
| ? | MM0042 | CAPSCREW - M10 X 1.50 X 25 | 6 | ||||
| ? | MM0713 | FLAT WASHER - M10 | 12 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 18 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 12 | ||||
| ? | EB2104 | STRAP, MOUNTING - R.H. | 1 | ||||
| ? | EB2105 | STRAP, MOUNTING - L.H. | 1 | ||||
| ? | MM0050 | CAPSCREW - M10 X 1.50 X 35 | 8 | ||||
| ? | EB2899 | WASHER (SPECIAL) | 6 | ||||
| ? | EB2102 | BAR | 2 | ||||
| ? | MM0064 | CAPSCREW - M10 X 1.50 X 45 | 4 | ||||
| ? | EC6553 | STEP | 1 | ||||
| ? | EH1491 | HANDRAIL, DIAGONAL LADDER | 2 | ||||
| ? | VC1387 | CAPSCREW - 1/2" - 13NC X 1" | 26 | ||||
| ? | WA4728 | FLAT WASHER - 1/2" | 38 | ||||
| ? | EH1976 | SHIELD | 1 | ||||
| ? | EL6084 | LADDER, LEFT DECK | 1 | ||||
| ? | MM0620 | CAPSCREW - M12 X 1.75 X 40 | 7 | ||||
| ? | MM0714 | FLAT WASHER - M12 | 7 | ||||
| ? | EG6848 | HANDRAIL, LEFT DECK LADDER - OUTSIDE | 1 | ||||
| ? | VC6561 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 8 | ||||
| ? | TR6643 | NUT - 1/2" - 13NC | 4 | ||||
| ? | EG0861 | BEAM, DIAGONAL | 1 | ||||
| ? | MM0047 | CAPSCREW - M10 X 1.50 X 30 | 2 | ||||
| ? | EL6081 | HANDRAIL, LEFT DECK LADDER - INSIDE | 1 |
