| Наименование | Страница | Код страницы |
|---|---|---|
| FLOW AMPLIFIER (PB9932) | 130 | 35461 |
| STEERING CYLINDER AND BEARINGS | 108 | 55690 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EK1040 | STEERING CYLINDER ASSEMBLY (SEE FIG 55690) | 2 | 55690 | |||
| ? | TG3309 | CLAMP, SPLIT | 12 | ||||
| ? | VN3466 | O-RING | 6 | ||||
| ? | C1603 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 20 | ||||
| ? | TG2341 | CAPSCREW - 3/8" - 16NC X 2 1/4" (SPECIAL) | 4 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 26 | ||||
| ? | HA7337 | HOSE | 2 | ||||
| ? | HA0153 | HOSE | 2 | ||||
| ? | PB6528 | COUPLING, DIAGNOSTIC | 2 | ||||
| ? | PB6041 | CAP, DUST | 2 | ||||
| ? | WB0594 | FITTING, STRAIGHT | 4 | ||||
| ? | PB8303 | CLAMP ASSEMBLY | 2 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 2 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 2 | ||||
| ? | EC1446 | TUBE | 2 | ||||
| ? | HA2463 | HOSE | 2 | ||||
| ? | PB9932 | FLOW AMPLIFIER (SEE INDEX) | 1 | 35461 | |||
| ? | WA4876 | FITTING, ELBOW - 90 DEG | 2 | ||||
| ? | TZ5901 | MANIFOLD | 1 | ||||
| ? | WB0599 | FITTING, STRAIGHT | 1 | ||||
| ? | WB0378 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | WB0522 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | TF8481 | CAPSCREW - 3/8" - 16NC X 4" (ZINC) | 2 |
