| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB9711 | BLANKET, EXHAUST | 1 | ||||
| ? | EF6781 | TUBE, EXHAUST - L.H. | 1 | ||||
| ? | PB9712 | BLANKET, EXHAUST | 1 | ||||
| ? | PB6183 | CLAMP, V-BAND | 2 | ||||
| ? | PB9713 | BLANKET, EXHAUST | 1 | ||||
| ? | EF6778 | TUBE, EXHAUST - R.H. | 1 | ||||
| ? | PB9714 | BLANKET, EXHAUST | 1 | ||||
| ? | TA6490 | CLAMP ASSEMBLY | 9 | ||||
| ? | C0312 | • LOCKWASHER - 3/8" | 18 | ||||
| ? | C1521 | • NUT - 3/8" - 16NC | 18 | ||||
| ? | TA6483 | • CLAMP | 9 | ||||
| ? | TA6491 | • U-BOLT - 3/8" - 16NC | 9 | ||||
| ? | PB7906 | MUFFLER, EXHAUST | 2 | ||||
| ? | PB7910 | BLANKET, EXHAUST | 2 | ||||
| ? | ED8393 | TUBE | 1 | ||||
| ? | EC1828 | TUBE | 1 | ||||
| ? | PB8315 | BLANKET, EXHAUST | 1 | ||||
| ? | EG4032 | TUBE | 1 | ||||
| ? | PC1549 | BLANKET, EXHAUST | 1 | ||||
| ? | MM0621 | CAPSCREW - M12 X 1.75 X 45 | 4 | ||||
| ? | MM0472 | LOCKWASHER - M12 | 4 | ||||
| ? | MM0462 | FLAT WASHER - M12 | 4 | ||||
| ? | MM0179 | NUT - M12 X 1.75 | 4 | ||||
| ? | EC1841 | BAR, FLAT | 4 | ||||
| ? | PB8314 | BLANKET, EXHAUST | 1 | ||||
| ? | EG4033 | TUBE | 1 | ||||
| ? | PC1548 | BLANKET, EXHAUST | 1 |
