| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | YA2986 | • PANEL, INSTRUMENT | 1 | ||||
| ? | SP8443 | • • BULB, LIGHT | 20 | ||||
| ? | PB6303 | • • GAUGE, WATER TEMPERATURE | 1 | ||||
| ? | PB6401 | • • OVERLAY KIT, BEZEL | 8 | ||||
| ? | PB8551 | • • GAUGE, OIL PRESSURE | 1 | ||||
| ? | PB6927 | • • GAUGE, VOLTMETER | 1 | ||||
| ? | PB6985 | • • SPEEDOMETER, DIGITAL (MPH) | 1 | ||||
| ? | PB6402 | • • OVERLAY KIT, BEZEL | 2 | ||||
| ? | TW5472 | • • LIGHT, TURN INDICATOR | 2 | ||||
| ? | VZ5080 | • • BULB, LIGHT | 3 | ||||
| ? | WA6639 | • • LEXAN OVERLAY, TURN SIGNAL | 1 | ||||
| ? | TY8743 | • • PANEL, INSERT - TURN SIGNAL | 1 | ||||
| ? | WA4605 | • • PHILLIPS SCREW - #10 - 24NC X 1/2" | 27 | ||||
| ? | TW3834 | • • INDICATOR, HIGH-BEAM | 1 | ||||
| ? | PB6984 | • • TACHOMETER, DIGITAL | 1 | ||||
| ? | WA6637 | • • LIGHT CLUSTER | 4 | ||||
| ? | CH1503 | • • LIGHT INSERT | 1 | ||||
| ? | WA4877 | • • MACHINE SCREW (FLAT HEAD) | 8 | ||||
| ? | CH1505 | • • LIGHT INSERT | 1 | ||||
| ? | WA6640 | • • LEXAN OVERLAY, TEST SWITCH | 1 | ||||
| ? | TX6341 | • • PANEL, INSERT - TEST SWITCH | 1 | ||||
| ? | PB6969 | • • SWITCH, ROCKER | 1 | ||||
| ? | CH1506 | • • LIGHT INSERT | 1 | ||||
| ? | CH1507 | • • LIGHT INSERT | 1 | ||||
| ? | PB7019 | • • LIGHT, INDICATOR | 3 | ||||
| ? | VL6234 | • • BULB, LIGHT | 7 | ||||
| ? | PB6972 | • • SWITCH, ROCKER | 6 | ||||
| ? | EB2431 | • • PANEL, INSERT | 1 | ||||
| ? | WA8912 | • • LEXAN OVERLAY, KEY SWITCH | 1 | ||||
| ? | TY8749 | • • PANEL, INSERT - KEY SWITCH | 1 | ||||
| ? | EB9458 | • • COVER, PLATE | 1 | ||||
| ? | VM7105 | • • SWITCH, KEY | 1 | ||||
| ? | TW5117 | • • RHEOSTAT | 1 | ||||
| ? | PB0529 | • • KNOB, RHEOSTAT | 1 | ||||
| ? | TY9878 | • • CONTROL, ELECTRIC WIPER | 1 | ||||
| ? | PB7026 | • • SWITCH, ROCKER | 1 | ||||
| ? | WA6651 | • • LEXAN OVERLAY, SWITCH | 1 | ||||
| ? | TY8741 | • • PANEL, INSERT - SWITCH | 1 | ||||
| ? | PB6307 | • • HOURMETER | 1 | ||||
| ? | PB6982 | • • BLANK INSERT | 1 | ||||
| ? | PB6926 | • • GAUGE, FUEL LEVEL | 1 | ||||
| ? | WA6652 | • • LEXAN OVERLAY, BRAKE | 1 | ||||
| ? | TY8742 | • • PANEL, INSERT - BRAKE | 1 | ||||
| ? | VJ8676 | • • SWITCH, HEATER | 1 | ||||
| ? | VJ8323 | • • KNOB | 1 | ||||
| ? | WA6644 | • • LEXAN OVERLAY, HEATER | 1 | ||||
| ? | TX6371 | • • PANEL, INSERT - HEATER | 1 | ||||
| ? | PB8987 | • • GAUGE, AIR CLEANER VACUUM | 2 | ||||
| ? | PB9050 | • • HOSE | 2 | ||||
| ? | PB9051 | • • FITTING - WITH FILTER | 2 | ||||
| ? | PB9056 | • • FITTING - COMPRESSION | 2 | ||||
| ? | WA0085 | • • O-RING | 2 | ||||
| ? | WB2144 | • • CHART, GRADE SPEED | 1 | ||||
| ? | PB6972 | • • SWITCH, ROCKER (FOG LIGHTS) (OPTIONAL) | 1 | ||||
| ? | EC5913 | • • HARNESS, MAIN (1) | 1 | ||||
| ? | TY7842 | • • HOUSING, P1-R1 (1) | 1 | ||||
| ? | TY7841 | • • HOUSING, P2-R2 (1) | 1 | ||||
| ? | PB7903 | • • LOUVER, BALL - W/ 2.50 HOSE | 2 | ||||
| ? | PB8164 | • • SWITCH (EMERGENCY ENGINE SHUTDOWN) | 1 | ||||
| ? | • • NOTE: (1) LOCATED ON BACK OF INSTRUMENT PANEL. | 65535 |
