| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE7657 | TUBE, OVERFLOW | 1 | ||||
| ? | VE6969 | CLIP, HOSE | 4 | ||||
| ? | VE7649 | BAFFLE, AIR - BOTTOM FELT | 4 | ||||
| ? | VE4000 | GROMMET, RUBBER | 1552 | ||||
| ? | VE6987 | SUPPORT, CENTER | 2 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 54 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 30 | ||||
| ? | C1528 | NUT - 3/4" - 16NF | 12 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 38 | ||||
| ? | VE1285 | BRACKET, X-BRACE | 2 | ||||
| ? | C5747 | CAPSCREW - 5/16" - 18NC X 3/4" | 4 | ||||
| ? | VE5442 | FLAT WASHER - 5/16" | 6 | ||||
| ? | C1520 | NUT - 5/16" - 18NC | 2 | ||||
| ? | VE7656 | ROD, X-BRACE | 2 | ||||
| ? | E3735 | FLAT WASHER - 3/8" | 8 | ||||
| ? | VE3999 | GROMMET, RUBBER | 1552 | ||||
| ? | VE7644 | TANK, TOP REAR | 1 | ||||
| ? | VE7642 | TANK, TOP FRONT | 1 | ||||
| ? | VE5320 | SUPPORT, CENTER | 2 | ||||
| ? | VE4005 | CAPSCREW - 3/8" - 16NC X 3/4" | 16 | ||||
| ? | C1614 | CAPSCREW - 1/2" - 13NC X 1 1/4" | 16 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 58 | ||||
| ? | VE3461 | NUT - 1/2" - 13NC | 16 | ||||
| ? | VE1219 | TUBE, STAY END | 64 | ||||
| ? | VE7647 | TANK, CENTER FRONT | 1 | ||||
| ? | VE7652 | SIDE MEMBER - RIGHT | 1 | ||||
| ? | VE7653 | SIDE MEMBER - LEFT | 1 | ||||
| ? | VE3460 | CAPSCREW - 1/2" - 13NC X 1" | 42 | ||||
| ? | VE7643 | TANK, BOTTOM FRONT | 1 | ||||
| ? | VE8683 | TANK, BOTTOM REAR | 1 | ||||
| ? | VE7650 | SIDE MEMBER - RIGHT | 1 | ||||
| ? | VE7651 | SIDE MEMBER - LEFT | 1 | ||||
| ? | VE7654 | RING, FAN | 1 | ||||
| ? | VE8684 | SHROUD | 1 | ||||
| ? | VE7646 | TANK, CENTER REAR | 1 | ||||
| ? | VE3475 | TUBES | 606 | ||||
| ? | VE6829 | TUBE ASSM | 946 | ||||
| ? | VE7648 | BAFFLE, AIR - TOP FELT | 4 |
