| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SM5281 | KNOB - TEMP CONTROL | 1 | ||||
| ? | SM5285 | PLATE | 1 | ||||
| ? | SM5282 | DECAL | 1 | ||||
| ? | SM5283 | HARNESS | 1 | ||||
| ? | SM5286 | MODULE, HEATER CONTROL | 1 | ||||
| ? | WA4513 | SCREW, SELF TAP - #10 - 24NC X 1/2" | 2 | ||||
| ? | SM5287 | COVER | 1 | ||||
| ? | EG6155 | HARNESS, JUMPER - POTENIOMETER TO CONTROL MODULE | 1 | ||||
| ? | EG6154 | HARNESS, HEATER POWER | 1 | ||||
| ? | VG2833 | HOSE, HEATER | 2 | ||||
| ? | HC0908 | CLAMP | 8 | ||||
| ? | TH0031 | HOSE, HEATER | 1 | ||||
| ? | TC1565 | CLAMP | 1 | ||||
| ? | TD0791 | CAPSCREW, 3/8" - 16NC X 1 1/4" | 1 | ||||
| ? | TR4436 | FLATWASHER, 3/8" | 5 | ||||
| ? | TC1231 | LOCKWASHER, 3/8" | 1 | ||||
| ? | TC1233 | NUT, 3/8" | 1 | ||||
| ? | EB0256 | HOSE, HEATER | 1 | ||||
| ? | SM5284 | VALVE, MOTORIZED - WATER CONTROL | 1 |
