| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | ED0191 | • PISTON | 1 | ||||
| ? | WA0720 | • • FLAT WASHER - 3/8" | 10 | ||||
| ? | C0312 | • • LOCKWASHER - 3/8" | 11 | ||||
| ? | C1602 | • • CAPSCREW - 3/8" - 16NC X 1" | 12 | ||||
| ? | PB2194 | • • CHARGING VALVE ASSM | 1 | ||||
| ? | TD7179 | • • CORE | 1 | ||||
| ? | TR9993 | • • CAP | 1 | ||||
| ? | TF1144 | • • O-RING | 1 | ||||
| ? | WA0052 | • • O-RING | 1 | ||||
| ? | VD5076 | • • GASKET | 1 | ||||
| ? | TZ9083 | • • PROTECTOR | 1 | ||||
| ? | TY8879 | • • PLUG, VENT | 2 | ||||
| ? | VF4319 | • • SCREW, BLEEDER | 1 | ||||
| ? | WA0106 | • • SEAL, O-RING | 2 | ||||
| ? | WA1281 | • • RING, BACKUP | 2 | ||||
| ? | WA2892 | • • PLATE, WARNING | 2 | ||||
| ? | R1073 | • • DRIVE SCREW - #6 X 3/16" | 8 | ||||
| ? | VJ3911 | • • OIL, SUSPENSION - STANDARD (5 GALLON CAN) | 3 | ||||
| ? | EC1973 | • • HOUSING | 1 | ||||
| ? | WA0362 | • • FLAT WASHER - 3/4" | 12 | ||||
| ? | VM4571 | • • CAPSCREW - 3/4" - 10NC X 2 1/2" | 12 | ||||
| ? | ED0183 | • • BEARING, BRONZE | 1 | ||||
| ? | H2981 | • • BALL, STEEL - 3/4" | 2 | ||||
| ? | VN6801 | • • CAPSCREW - 3/4" - 10NC X 3 1/2" (SOCKET HEAD) | 24 | ||||
| ? | TZ0320 | • • BEARING, BRONZE | 1 | ||||
| ? | TY8475 | • • SHIELD | 2 | ||||
| ? | PB7976 | • • SEAL, ROD BUFFER - 12.00" | 1 | ||||
| ? | PB8564 | • • SEAL, ROD - DOUBLE LIP - 12.00" | 1 | ||||
| ? | WA4519 | • • SEAL, WIPER - 12.00" | 1 | ||||
| ? | VZ4269 | • • GUARD, VALVE | 1 | ||||
| ? | TZ9093 | • • PLUG, VENT | 1 | ||||
| ? | TZ8637 | • • PLUG, SENSOR | 1 | ||||
| ? | • • (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY) | 65535 |
