| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB0294 | • FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | HA1251 | • • HOSE | 1 | ||||
| ? | TJ0265 | • • HOSE, HEATER | 1 | ||||
| ? | TG5601 | • • CONNECTOR | 1 | ||||
| ? | HC0908 | • • CLAMP | 1 | ||||
| ? | VN9914 | • • CLAMP | 3 | ||||
| ? | TR3662 | • • CLAMP | 2 | ||||
| ? | VH9969 | • • WELD STUD - 3/8" - 16NC X 3/4" | 14 | ||||
| ? | C1521 | • • NUT - 3/8" - 16NC | 14 | ||||
| ? | C0312 | • • LOCKWASHER - 3/8" | 14 | ||||
| ? | WA0720 | • • FLAT WASHER - 3/8" - HARDENED | 5 | ||||
| ? | TR9441 | • • CLAMP | 4 | ||||
| ? | TC1565 | • • CLAMP | 9 | ||||
| ? | HA0186 | • • HOSE | 1 | ||||
| ? | VD9903 | • • HOSE | 1 | ||||
| ? | SD5203 | • • NIPPLE, CLOSE | 1 | ||||
| ? | VH3081 | • • ELBOW, PIPE 90 DEG | 1 | ||||
| ? | HA5785 | • • HOSE | 1 |
