| Наименование | Страница | Код страницы |
|---|---|---|
| FLOW AMPLIFIER VALVE PC2162 | 520 | 61479 |
| BLEED DOWN MANIFOLD PC1493 | 522 | 61573 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PC2162 | FLOW AMPLIFIER VALVE (SEE INDEX) | 1 | 61479 | |||
| ? | PC1493 | BLEED DOWN MANIFOLD (SEE INDEX) | 1 | 61573 | |||
| ? | EJ2746 | TUBE | 1 | ||||
| ? | EJ2745 | TUBE | 1 | ||||
| ? | WA4709 | CLAMP, HYDRA ZORB - 1 1/4" | 2 | ||||
| ? | HA3288 | HOSE | 1 | ||||
| ? | HA7919 | HOSE | 1 | ||||
| ? | TC6058 | CLAMP, VINYL - 1 1/2" I.D. | 5 | ||||
| ? | HA7918 | HOSE | 1 | ||||
| ? | HA8416 | HOSE | 1 | ||||
| ? | HA7996 | HOSE | 2 | ||||
| ? | HA7828 | HOSE | 1 | ||||
| ? | HA7690 | HOSE | 1 | ||||
| ? | WA4712 | CLAMP, HYDRA ZORB - 2" | 2 | ||||
| ? | HA7688 | HOSE | 1 | ||||
| ? | EJ3891 | CLAMP ASSEMBLY | 5 | ||||
| ? | HA5582 | HOSE | 1 | ||||
| ? | HA7331 | HOSE | 1 | ||||
| ? | TF8077 | CLAMP, SPLIT FLANGE | 2 | ||||
| ? | VG9097 | O-RING | 1 | ||||
| ? | C1603 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 4 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 4 | ||||
| ? | TF3237 | CLAMP, SPLIT FLANGE - 1 1/4" | 2 | ||||
| ? | VG9096 | O-RING | 1 | ||||
| ? | C1609 | CAPSCREW - 7/16" - 14NC X 1 1/2" | 4 | ||||
| ? | C5775 | LOCKWASHER - 7/16" | 4 | ||||
| ? | PC0170 | VALVE, SHUTOFF | 1 | ||||
| ? | VH6718 | CLAMP, SPLIT FLANGE - 2 1/2" | 2 | ||||
| ? | WA0232 | O-RING | 1 | ||||
| ? | C1623 | CAPSCREW - 1/2" - 13NC X 3 3/4" | 4 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 4 | ||||
| ? | HA7687 | HOSE | 1 | ||||
| ? | HA7341 | HOSE | 1 |
