| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EK9382 | LIGHT, LED - GREEN | 2 | ||||
| ? | EK9381 | LIGHT, LED - YELLOW | 2 | ||||
| ? | EK9380 | LIGHT, LED - RED | 2 | ||||
| ? | TG1929 | MACHINE SCREW - #10 - 24NC X 1/2" | 24 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 12 | ||||
| ? | DF0017 | NUT - #10 - 24NC | 24 | ||||
| ? | VN9762 | FLAT WASHER - #4 | 12 | ||||
| ? | EL8629 | COVER | 1 | ||||
| ? | DC5004 | MACHINE SCREW - #12 - 24NC X 1/2" | 4 | ||||
| ? | VD2047 | LOCKWASHER - #12 | 4 | ||||
| ? | VC6041 | GROMMET, RUBBER | 1 | ||||
| ? | TV3555 | PLUG, BUTTON - 1 3/8" | 1 | ||||
| ? | MM0603 | CAPSCREW - M10 X 1.50 X 16 | 4 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 4 | ||||
| ? | EK3852 | HOUSING, PLMIII LIGHT | 1 | ||||
| ? | EL9919 | COVER, HOUSING | 1 | ||||
| ? | WA2853 | SCREW, SELF-TAPPING - #12 - 24NC X 5/8" | 7 |
