Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
EK4993 |
DIODE BOARD ASSEMBLY - DB1 (SEE FIG 55613) |
1 |
|
55613 |
|
|
? |
EC8825 |
NAME PLATE - DB1 |
2 |
|
|
|
|
? |
EG8333 |
RESISTOR - 20 OHM |
1 |
|
|
|
|
? |
SM3124 |
DIODE |
1 |
|
|
|
|
? |
EG0664 |
RESISTOR - 270 OHM |
1 |
|
|
|
|
? |
EK4991 |
RELAY BOARD ASSEMBLY - RB6, RB7, RB8 (SEE FIG 55613) |
4 |
|
55613 |
|
|
? |
EC8824 |
NAME PLATE - RB6 |
2 |
|
|
|
|
? |
WB2280 |
NAME PLATE - RB7 |
2 |
|
|
|
|
? |
WB3237 |
NAME PLATE - RB9 |
2 |
|
|
|
|
? |
WB2733 |
NAME PLATE - RB8 |
2 |
|
|
|
|
? |
MM0027 |
CAPSCREW - M6 X 1.00 X 25 |
28 |
|
|
|
|
? |
MM0459 |
FLAT WASHER - M6 |
69 |
|
|
|
|
? |
MM0469 |
LOCKWASHER - M6 |
41 |
|
|
|
|
? |
MM0176 |
NUT - M6 X 1.00 |
54 |
|
|
|
|
? |
7861-92-5330 |
SENSOR, ANGLE |
1 |
|
|
|
|
? |
EL7628 |
NAME PLATE - INCLINOMETER |
2 |
|
|
|
|
? |
TG5720 |
CAPSCREW - 3/8" - 16NC X 1" |
3 |
|
|
|
|
? |
TR9008 |
JAM NUT - 3/8" - 16NC |
3 |
|
|
|
|
? |
TC1231 |
LOCKWASHER - 3/8" |
3 |
|
|
|
|
? |
TR4436 |
FLAT WASHER - 3/8" |
3 |
|
|
|
|
? |
PC2667 |
TIMER, AUTO LUBE |
1 |
|
|
|
|
? |
WB2281 |
NAME PLATE - LUBE TIMER |
2 |
|
|
|
|
? |
PB7276 |
RELAY - 24V, 50 AMP |
2 |
|
|
|
|
? |
WB2836 |
NAME PLATE - 12V POWER RELAY |
2 |
|
|
|
|
? |
WB2289 |
NAME PLATE - CONTROL POWER RELAY |
2 |
|
|
|
|
? |
PB7202 |
INSULATOR, GLASTIC |
2 |
|
|
|
|
? |
EM8612 |
ROD, THREADED |
2 |
|
|
|
|
? |
TD1684 |
NUT - 5/16" - 18NC |
2 |
|
|
|
|
? |
SC4174 |
LOCKWASHER - 5/16" |
2 |
|
|
|
|
? |
TV0177 |
FLAT WASHER - 5/16" |
4 |
|
|
|
|
? |
EG2305 |
BAR, BUS |
1 |
|
|
|
|
? |
MM0584 |
CAPSCREW - M6 X 1.00 X 30 |
5 |
|
|
|
|
? |
EK0731 |
ROD, THREADED |
8 |
|
|
|
|
? |
TZ7377 |
NAME, PLATE - 24VDC |
1 |
|
|
|
|
? |
WB2303 |
NAME PLATE - GB31 |
1 |
|
|
|
