| Наименование | Страница | Код страницы |
|---|---|---|
| LIGHT ASSEMBLY (SUPER HALOGEN) | 338 | 42185 |
| JUNCTION BOX ASSEMBLY - REAR EK1413 | 386 | 60960 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EK1413 | JUNCTION BOX ASSEMBLY - REAR (SEE INDEX) | 1 | 60960 | |||
| ? | MM0603 | CAPSCREW - M10 X 1.50 X 16 | 4 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 7 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 3 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 2 | ||||
| ? | WB3098 | CLAMP, CUSHIONED - 3/8" | 1 | ||||
| ? | WB3093 | CLAMP, CUSHIONED - 1" | 4 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 8 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 8 | ||||
| ? | SP6153 | LOCKWASHER - 3/8" (EXTERNAL - INTERNAL TOOTH) | 4 | ||||
| ? | 736131C2 | ALARM, BACKUP | 2 | ||||
| ? | C5753 | CAPSCREW - 3/8" - 16NC X 4" | 4 | ||||
| ? | EK5647 | HARNESS, BLOWER PRESSURE SWITCH | 1 | ||||
| ? | XB3083 | HARNESS, AXLE HOUSING | 1 | ||||
| ? | SP8708 | LOCKWASHER - 5/16" (EXTERNAL - INTERNAL TOOTH) | 6 | ||||
| ? | PC1913 | STOP/TAIL LIGHT - RED (LED) | 2 | ||||
| ? | AK4695 | • LENS/REFLECTOR UNIT - RED | 1 | ||||
| ? | AK4705 | • HOUSING ASSEMBLY - UNIVERSAL | 1 | ||||
| ? | PC1914 | RETARD LIGHT - AMBER (LED) | 2 | ||||
| ? | AK4696 | • LENS/REFLECTOR UNIT - RETARD | 1 | ||||
| ? | AK4704 | • HOUSING ASSEMBLY - UNIVERSAL | 1 | ||||
| ? | AK7513 | BACKUP LIGHT ASSEMBLY (SEE FIG 42185) | 2 | 42185 |
