| Наименование | Страница | Код страницы |
|---|---|---|
| WIPER/WASHER TIMER DELAY MODULES | 318 | 60928 |
| D.I.D. PANEL INSTALLATION | 316 | 61502 |
| TERMINAL BOARDS 2/2 | 620 | 64070A |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EK4010 | MAT, PROTECTIVE RUBBER | 1 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 7 | ||||
| ? | MM0177 | NUT - M8 X 1.25 | 7 | ||||
| ? | VC7674 | CLAMP, VINYL - 2 7/16" I.D. | 5 | ||||
| ? | WB3096 | CLAMP, CUSHIONED - 1 1/4" | 2 | ||||
| ? | VS8192 | BOARD, TERMINAL (SEE FIG 64070A) | 1 | 64070A | |||
| ? | TG1929 | MACHINE SCREW - #10 - 24NC X 1/2" | 2 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 2 | ||||
| ? | VC5344 | FLAT WASHER - #10 | 2 | ||||
| ? | EB7418 | BAR, BUS | 1 | ||||
| ? | WB0820 | NAME PLATE - TB10 | 1 | ||||
| ? | VM2951 | SCREW, SELF-TAPPING - #6 - 32NC X 5/16" | 2 | ||||
| ? | WB3180 | STRIP, CIRCUIT ID | 1 | ||||
| ? | WA3367 | NUT ASSEMBLY | 12 |
