| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HA8354 | HOSE (STEERING VALVE PORT L & R) | 2 | ||||
| ? | HA6343 | HOSE (STEERING VALVE PORT T & P) | 2 | ||||
| ? | HA7436 | HOSE (STEERING VALVE PORT LS) | 1 | ||||
| ? | HA7285 | HOSE (HOIST PILOT VALVE RETURN) | 1 | ||||
| ? | HA7421 | HOSE (REAR BRAKE RELAY VALVE SIGNAL) | 1 | ||||
| ? | HA8696 | HOSE (LEFT FRONT BRAKE APPLICATION) | 1 | ||||
| ? | HA8695 | HOSE (RIGHT FRONT BRAKE APPLICATION) | 1 | ||||
| ? | HA8452 | HOSE (HOIST PILOT POWER UP & POWER DOWN) | 2 | ||||
| ? | HA8351 | HOSE (HOIST PILOT VALVE SUPPLY) | 1 | ||||
| ? | HA7836 | HOSE (BRAKE SUPPLY) | 1 | ||||
| ? | HA8353 | HOSE (BRAKE RETURN) | 1 | ||||
| ? | HA7422 | HOSE (PARKING BRAKE) | 1 | ||||
| ? | HA7420 | HOSE (REAR BRAKE RELAY VALVE PRESSURE) | 1 | ||||
| ? | HA8350 | HOSE (REAR BRAKE ACCUMULATOR) | 1 | ||||
| ? | HA8086 | HOSE (FRONT BRAKE ACCUMULATOR) | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 8 | ||||
| ? | MM0461 | FLAT WASHER - M10 (HARDENED) | 8 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 28 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 20 | ||||
| ? | EL3752 | BRACKET, CLAMP | 4 | ||||
| ? | TY8375 | SPACER | 20 | ||||
| ? | WB1300 | CLAMP, CUSHIONED - 5/8" | 4 | ||||
| ? | WB3096 | CLAMP, CUSHIONED - 1 1/4" | 12 | ||||
| ? | WB3092 | CLAMP, CUSHIONED - 7/8" | 52 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 4 |
