| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PC2399 | FUSE, 1 AMP | 1 | ||||
| ? | XB1464 | HARNESS, FUSE PANEL POWER | 1 | ||||
| ? | 421-06-11970 | • DIODE - 3 AMP | 1 | ||||
| ? | WB2941 | NAME PLATE, FUSE BLOCK 1 | 1 | ||||
| ? | SD5390 | SCREW - #10 - 32NC X 1" | 12 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 12 | ||||
| ? | VC5344 | FLAT WASHER - #10 | 12 | ||||
| ? | WB2942 | NAME PLATE, FUSE BLOCK 2 | 1 | ||||
| ? | EK2512 | NAME PLATE, FUSE BLOCK 3 | 1 | ||||
| ? | 08041-01000 | FUSE, 10 AMP | 15 | ||||
| ? | WB2200 | NAME PLATE, DLS | 1 | ||||
| ? | PC0254 | SWITCH, ROCKER | 1 | ||||
| ? | WB3655 | NAME PLATE, DATA PORTS | 1 | ||||
| ? | 08041-00500 | FUSE, 5 AMP | 9 | ||||
| ? | XB2118 | LABEL, FUSE PANEL | 1 | ||||
| ? | 08041-02000 | FUSE, 20 AMP | 8 | ||||
| ? | 08041-01500 | FUSE, 15 AMP | 10 |
