| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EK5636 | PLM LIGHT ASSEMBLY - LH | 1 | ||||
| ? | EK5637 | PLM LIGHT ASSEMBLY - RH | 1 | ||||
| ? | EK9382 | • LIGHT, LED - GREEN | 1 | ||||
| ? | EK9381 | • LIGHT, LED - YELLOW | 1 | ||||
| ? | EK9380 | • LIGHT, LED - RED | 1 | ||||
| ? | EB4084 | • COVER, HOUSING | 1 | ||||
| ? | EK3852 | • HOUSING, INDICATOR LIGHT | 1 | ||||
| ? | WA2853 | • SCREW, SELF-TAPPING - #12 - 24NC X 5/8" | 7 | ||||
| ? | TG1929 | • SCREW - #10 - 24NC X 1/2" | 12 | ||||
| ? | DC3101 | • LOCKWASHER - #10 | 13 | ||||
| ? | DF0017 | • NUT - #10 - 24NC | 13 | ||||
| ? | HD6007 | • MACHINE SCREW - #10 - 24NC X 3/4" | 1 | ||||
| ? | SD4245 | • LOCKWASHER - #10 (EXTERNAL TOOTH) | 1 | ||||
| ? | VC5344 | • FLAT WASHER - #10 | 1 | ||||
| ? | (QUANTITIES SHOWN FOR ONE SIDE ONLY.) |
