Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
EK5637 |
PLM LIGHT ASSEMBLY - RH (SEE FIG 42375) |
1 |
|
42375 |
|
|
? |
MM0603 |
CAPSCREW - M10 X 1.50 X 16 |
8 |
|
|
|
|
? |
MM0461 |
FLAT WASHER - M10 |
37 |
|
|
|
|
? |
MM0178 |
NUT - M10 X 1.50 |
31 |
|
|
|
|
? |
WB3093 |
CLAMP, CUSHION - 1" |
11 |
|
|
|
|
? |
WB1301 |
CLAMP, CUSHION - 1/4" |
7 |
|
|
|
|
? |
CH4174 |
CABLE |
1 |
|
|
|
|
? |
WB3097 |
CLAMP, CUSHION - 1/2" |
6 |
|
|
|
|
? |
VN5153 |
WIRE, GROUND |
1 |
|
|
|
|
? |
TV3461 |
CAPSCREW - 3/8" - 16NC X 5/8" |
1 |
|
|
|
|
? |
TR4436 |
FLAT WASHER - 3/8" |
5 |
|
|
|
|
? |
WB1302 |
CLAMP, CUSHION - 5/16 |
6 |
|
|
|
|
? |
TC1233 |
NUT - 3/8" - 16NC |
1 |
|
|
|
|
? |
TG5720 |
CAPSCREW - 3/8" - 16NC X 1" |
3 |
|
|
|
|
? |
TC1231 |
LOCKWASHER - 3/8" |
3 |
|
|
|
|
? |
EG9194 |
MOUNT |
1 |
|
|
|
|
? |
TY0616 |
BRACKET, MOUNTING |
1 |
|
|
|
|
? |
AK7519 |
FLOOD LIGHT ASSEMBLY (SEE FIG 60883) |
1 |
|
60883 |
|
|
? |
VY2784 |
GROMMET, RUBBER |
1 |
|
|
|
|
? |
VG7811 |
LOCKNUT - 1/2" - 13NC |
2 |
|
|
|
|
? |
SR7215 |
CAPSCREW - 1/2" - 13NC X 7 1/2" |
2 |
|
|
|
|
? |
PC1867 |
LIGHT, CLEARANCE - AMBER (LED) |
1 |
|
|
|
|
? |
AK4701 |
• LENS/REFLECTOR UNIT - AMBER |
1 |
|
|
|
|
? |
AK4702 |
• HOUSING, FLANGE |
1 |
|
|
|
|
? |
MM0349 |
MACHINE SCREW - M5 X .8 X 12 |
3 |
|
|
|
|
? |
MM0379 |
LOCKWASHER - M5 |
3 |
|
|
|
|
? |
MM0373 |
NUT - M5 X 0.8 |
3 |
|
|
|
|
? |
EG1107 |
PLATE, MOUNTING |
1 |
|
|
|
|
? |
MM0594 |
CAPSCREW - M8 X 1.25 X 25 |
4 |
|
|
|
|
? |
MM0460 |
FLAT WASHER - M8 |
4 |
|
|
|
|
? |
MM0470 |
LOCKWASHER - M8 |
4 |
|
|
|
|
? |
XB0731 |
HARNESS, R.H. DECK LIGHTING |
1 |
|
|
|
