| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB0274 | FITTING, 90 DEGREE ELBOW | 1 | ||||
| ? | SD5210 | BUSHING | 1 | ||||
| ? | WA4710 | CLAMP, HYDRA ZORB - 1 1/2" | 7 | ||||
| ? | HA8481 | HOSE (RETURN) | 1 | ||||
| ? | HA8611 | HOSE (SUPPLY) | 1 | ||||
| ? | HA7609 | HOSE | 1 | ||||
| ? | WB0474 | FITTING, STRAIGHT | 2 | ||||
| ? | PB9283 | VALVE, BALL SHUTOFF | 1 | ||||
| ? | EM8890 | DOOR, FUEL | 1 | ||||
| ? | EM8889 | SHOULDER BOLT - 3/8" - 16NC X 9" | 1 | ||||
| ? | VC7836 | FLAT WASHER - 1/2" | 1 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 1 | ||||
| ? | TC1233 | NUT - 3/8" - 16NC | 1 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 1 | ||||
| ? | EM8894 | PLATE, COVER | 1 | ||||
| ? | TG1929 | SCREW - #10 - 24NC X 1/2" | 4 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 4 | ||||
| ? | DF0017 | NUT - #10 - 24NC | 4 |
