| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-57-10000 | SEAT BELT ASSEMBLY | 1 | ||||
| ? | XA5492 | TETHER KIT, EXTERNAL | 1 | ||||
| ? | XA5507 | BACKREST ASSEMBLY | 1 | ||||
| ? | XA5489 | • COVER, BACKREST | 1 | ||||
| ? | XA5490 | • HEADREST | 1 | ||||
| ? | XA5509 | • LUMBAR ASSEMBLY | 1 | ||||
| ? | XA5520 | CUSHION ASSEMBLY, SEAT | 1 | ||||
| ? | XA5505 | • COVER, SEAT CUSHION | 1 | ||||
| ? | XA5506 | • HANDLE, SEAT CUSHION ADJUSTER | 1 | ||||
| ? | XA5521 | ARMREST KIT, LH | 1 | ||||
| ? | XA5522 | ARMREST KIT RH | 1 | ||||
| ? | XA5518 | COVER, REAR | 1 | ||||
| ? | XA5493 | BOLT KIT, SHOULDER | 1 | ||||
| ? | XA5512 | HANDLE ASSEMBLY, BACKREST ADJUSTMENT | 1 | ||||
| ? | XA5495 | ADJUSTER, INCLINATION | 1 | ||||
| ? | XA5513 | SIDE COVER, LH | 1 | ||||
| ? | XA5515 | VALVE | 1 | ||||
| ? | XA5514 | SWITCH, HEATER | 1 | ||||
| ? | XA5516 | ADJUSTER, SHOCK ABSORBER | 1 | ||||
| ? | XA5497 | SHOCK ABSORBER, ADJUSTABLE | 1 | ||||
| ? | XA5498 | SPRING, AIR | 1 | ||||
| ? | BF0501 | RELAY | 1 | ||||
| ? | XA5503 | SLIDE SET | 1 | ||||
| ? | XA5504 | • HANDLE, SLIDE | 1 | ||||
| ? | XA5499 | COMPRESSOR | 1 | ||||
| ? | XA5496 | ADJUSTER, WEIGHT/HEIGHT | 1 | ||||
| ? | XA5502 | FASTENERS KIT | 1 | ||||
| ? | XA5501 | BELLOWS | 1 | ||||
| ? | XA5517 | COVER, FRONT | 1 | ||||
| ? | XA5511 | BOLT, LOCKING | 1 | ||||
| ? | XA5494 | GLIDES | 1 | ||||
| ? | XA5963 | SIDE COVER, RH | 1 | ||||
| ? | XA5519 | FRAME ASSEMBLY, SEAT | 1 | ||||
| ? | XA6101 | RISER | 1 | ||||
| ? | XA5523 | COVER, SHOULDER BELT | 1 |
