Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
WB1170 |
CLAMP, T-BOLT |
4 |
|
|
|
|
? |
WB1169 |
CLAMP, T-BOLT |
2 |
|
|
|
|
? |
PC2055 |
ELBOW, RUBBER |
2 |
|
|
|
|
? |
EJ9911 |
ROD, THREADED |
3 |
|
|
|
|
? |
WB1177 |
CLAMP, T-BOLT |
12 |
|
|
|
|
? |
PC1115 |
HOSE, HUMP |
2 |
|
|
|
|
? |
EG7576 |
CLAMP, DOUBLE |
2 |
|
|
|
|
? |
EK1645 |
ANGLE |
1 |
|
|
|
|
? |
EK2341 |
ROD, THREADED |
1 |
|
|
|
|
? |
EJ9920 |
BRACKET, MOUNTING |
1 |
|
|
|
|
? |
EK1726 |
ROD, THREADED |
1 |
|
|
|
|
? |
EL6893 |
BRACKET, MOUNTING |
1 |
|
|
|
|
? |
MM0617 |
CAPSCREW - M12 X 1.75 X 25 |
4 |
|
|
|
|
? |
MM0472 |
LOCKWASHER - M12 |
4 |
|
|
|
|
? |
MM0462 |
FLAT WASHER - M12 |
4 |
|
|
|
|
? |
58F-02-00160 |
AIR CLEANER ASSEMBLY (SEE INDEX) |
1 |
|
43406 |
|
|
? |
TB1019 |
GUARD, RAIN - LH |
1 |
|
|
|
|
? |
TB1406 |
GUARD, RAIN |
1 |
|
|
|
|
? |
TB1018 |
GUARD, RAIN - RH |
1 |
|
|
|
|
? |
TR2961 |
CAPSCREW - 5/8" - 11NC X 1" |
4 |
|
|
|
|
? |
VC1390 |
LOCKWASHER - 5/8" |
4 |
|
|
|
|
? |
TR9082 |
FLAT WASHER - 5/8" |
4 |
|
|
|
|
? |
EL8237 |
TUBE |
1 |
|
|
|
|
? |
EL8235 |
TUBE |
1 |
|
|
|
|
? |
EL6886 |
TUBE |
1 |
|
|
|
|
? |
EL6895 |
ANGLE |
1 |
|
|
|
|
? |
MM0606 |
CAPSCREW - M10 X 1.50 X 30 |
2 |
|
|
|
|
? |
MM0713 |
FLAT WASHER - M10 |
4 |
|
|
|
|
? |
VC8762 |
CAPSCREW - 3/8" - 16NC X 1 1/2" |
3 |
|
|
|
|
? |
WA4726 |
FLAT WASHER - 3/8" |
6 |
|
|
|
|
? |
HE5611 |
LOCKNUT - 3/8" - 16NC |
3 |
|
|
|
|
? |
EL6887 |
TUBE |
1 |
|
|
|
|
? |
58F-09-00450 |
CAPSCREW - 5/8" - 11NC X 4 1/2" |
13 |
|
|
|
|
? |
WA4729 |
FLAT WASHER - 5/8" |
13 |
|
|
|
|
? |
VW7882 |
HOSE, HUMP |
1 |
|
|
|
|
? |
WB1179 |
CLAMP, T-BOLT |
4 |
|
|
|
|
? |
TX6040 |
ELBOW, RUBBER |
1 |
|
|
|
|
? |
EJ9909 |
CLAMP |
4 |
|
|
|
|
? |
WA0471 |
CAPSCREW - 1/2" - 13NC X 2 1/4" |
10 |
|
|
|
|
? |
WA4728 |
FLAT WASHER - 1/2" |
20 |
|
|
|
|
? |
DF3500 |
LOCKNUT - 1/2" - 13NC |
10 |
|
|
|
|
? |
PC1247 |
ROD END |
10 |
|
|
|
|
? |
TL8151 |
JAM NUT - 1/2" - 20NF |
10 |
|
|
|
