| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XB2397 | LADDER, DIAGONAL | 1 | ||||
| ? | MM0619 | CAPSCREW - M12 X 1.75 X 35 | 26 | ||||
| ? | MM0462 | FLAT WASHER - M12 | 24 | ||||
| ? | EJ6569 | SHIM | 4 | ||||
| ? | EJ6571 | SHIM | 4 | ||||
| ? | EL0144 | SUPPORT, DIAGONAL LADDER | 1 | ||||
| ? | MM0621 | CAPSCREW - M12 X 1.75 X 45 | 4 | ||||
| ? | MM0012 | CAPSCREW - M16 X 2.00 X 25 | 12 | ||||
| ? | MM0706 | FLAT WASHER - M16 | 12 | ||||
| ? | MM0179 | NUT - M12 X 1.75 | 6 | ||||
| ? | EM3891 | HANDRAIL, DIAGONAL LADDER | 1 | ||||
| ? | DF3500 | LOCKNUT - 1/2" - 13NC | 1 | ||||
| ? | MM0714 | FLAT WASHER - M12 | 18 | ||||
| ? | MM0472 | LOCKWASHER - M12 | 10 | ||||
| ? | VC4898 | CAPSCREW - 1/2" - 13NC X 2 1/2" | 1 | ||||
| ? | WA4728 | FLAT WASHER - 1/2" | 4 | ||||
| ? | EM3894 | CLAMP | 3 | ||||
| ? | 58F-54-20460 | HANDRAIL, DIAGONAL LADDER PLATFORM | 1 | ||||
| ? | EM0573 | BRACKET | 1 | ||||
| ? | EM4603 | ROD, THREADED | 1 | ||||
| ? | VP3771 | MOUNT, SHOCK | 1 | ||||
| ? | TL8151 | JAM NUT - 1/2" - 20NF | 3 | ||||
| ? | EK9095 | WASHER | 1 | ||||
| ? | EK9094 | WASHER | 1 | ||||
| ? | PC1247 | ROD END | 1 | ||||
| ? | PB9890 | BUMPER, RUBBER | 2 | ||||
| ? | TR6008 | FLAT WASHER - 1/2" | 2 | ||||
| ? | VG7146 | CAPSCREW - 1/2" - 13NC X 3/4" | 2 |
