| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EM8980 | REAR SUSPENSION ASSEMBLY | 1 | ||||
| ? | EM8981 | REAR SUSPENSION ASSEMBLY - COLD WEATHER | 1 | ||||
| ? | EK6522 | • HOUSING | 1 | ||||
| ? | TY8879 | • PLUG, VENT | 1 | ||||
| ? | PC2588 | • BEARING, PISTON | 1 | ||||
| ? | PC2587 | • BEARING, ROD | 1 | ||||
| ? | EK8138 | • RETAINER, BEARING | 1 | ||||
| ? | VN9140 | • CAPSCREW - 3/4" - 10NC X 4" | 24 | ||||
| ? | WA0362 | • FLAT WASHER - 3/4" (HARDENED) | 24 | ||||
| ? | EJ6733 | • COVER | 1 | ||||
| ? | C1603 | • CAPSCREW - 3/8" - 16NC X 1 1/4" | 2 | ||||
| ? | WA0720 | • FLAT WASHER - 3/8" (HARDENED) | 7 | ||||
| ? | C0312 | • LOCKWASHER - 3/8" | 7 | ||||
| ? | PC0626 | • SEAL, BUFFER (1) | 1 | ||||
| ? | PC0625 | • SEAL, DOUBLE LIP (1) | 1 | ||||
| ? | PC0627 | • SEAL, WIPER (1) | 1 | ||||
| ? | EM1582 | • PISTON | 1 | ||||
| ? | VM0313 | • PLUG | 4 | ||||
| ? | PB2194 | • CHARGING VALVE ASSEMBLY (1)/(2) | 1 | ||||
| ? | TD7179 | • • CORE, VALVE | 1 | ||||
| ? | TR9993 | • • CAP, VALVE | 1 | ||||
| ? | TF1144 | • • O-RING, HOUSING | 1 | ||||
| ? | WA0052 | • • O-RING, VALVE STEM | 1 | ||||
| ? | VD5076 | • GASKET, FLAT (1)/(2) | 1 | ||||
| ? | WA2892 | • PLATE, DANGER (1) | 2 | ||||
| ? | WA3134 | • SCREW | 8 | ||||
| ? | WA0180 | • SEAL, O-RING (1) | 1 | ||||
| ? | PC0673 | • RING, BACKUP (1) | 1 | ||||
| ? | TZ8637 | • PLUG, SENSOR | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | AK4063 | SUSPENSION OIL W/ FRICTION MODIFIER (5 GAL) | |||||
| ? | AK4064 | SUSPENSION OIL W/ FRICTION MODIFIER (55 GAL) | |||||
| ? | AK4065 | SUSPENSION OIL W/ FRICTION MODIFIER (5 GAL) - COLD WEATHER | |||||
| ? | AK4066 | SUSPENSION OIL W/ FRICTION MODIFIER (55 GAL) - COLD WEATHER | |||||
| ? | AK5239 | NOTE: (1) INCLUDED IN AK5239 SEAL KIT. | |||||
| ? | RK1887 | (2) INCLUDED IN RK1887 CHARGING VALVE KIT. |
