| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EJ9915 | ROD, THREADED | 1 | ||||
| ? | EK5667 | ROD, THREADED | 1 | ||||
| ? | EK2341 | ROD, THREADED | 2 | ||||
| ? | EJ9910 | ROD, THREADED | 1 | ||||
| ? | EK1741 | ROD, THREADED | 1 | ||||
| ? | EJ9909 | CLAMP | 6 | ||||
| ? | VC4898 | CAPSCREW - 1/2" - 13NC X 2 1/2" | 6 | ||||
| ? | TA6490 | CLAMP ASSEMBLY | 2 | ||||
| ? | TA6483 | • CLAMP | 1 | ||||
| ? | TA6491 | • U-BOLT - 3/8" - 16NC | 1 | ||||
| ? | C0312 | • LOCKWASHER - 3/8" | 2 | ||||
| ? | C1521 | • NUT - 3/8" - 16NC | 2 | ||||
| ? | C1547 | FLAT WASHER - 3/8" | 4 | ||||
| ? | EJ5567 | BRACKET, SHELF - L.H. | 1 | ||||
| ? | MM0462 | FLAT WASHER - M12 | 2 | ||||
| ? | MM0616 | CAPSCREW - M12 X 1.75 X 20 | 2 | ||||
| ? | PC1247 | ROD END, FEMALE | 12 | ||||
| ? | WA4728 | FLAT WASHER - 1/2" (HARDENED) | 24 | ||||
| ? | DF3500 | LOCKNUT - 1/2" - 13NC | 12 | ||||
| ? | TL8151 | JAM NUT - 1/2" - 20NF | 12 | ||||
| ? | WA0471 | CAPSCREW - 1/2" - 13NC X 2 1/4" | 6 | ||||
| ? | C1641 | CAPSCREW - 5/8" - 11NC X 4 1/2" | 15 | ||||
| ? | WA0361 | FLAT WASHER - 5/8" (HARDENED) | 25 | ||||
| ? | C1629 | CAPSCREW - 5/8" - 11NC X 1 3/4" | 10 |
