| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VG7043 | RELAY - CPR & GFR | 1 | ||||
| ? | VS8980 | CORE | 1 | ||||
| ? | VS9161 | CLAMP | 1 | ||||
| ? | VP9576 | ARMATURE | 1 | ||||
| ? | VS9254 | ARMATURE | 1 | ||||
| ? | VM0251 | FINGER/TIPS AND SHUNT | 3 | ||||
| ? | VM0240 | SPRING | 3 | ||||
| ? | VS9224 | SEAT, SPRING | 1 | ||||
| ? | VM0241 | SPRING | 2 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 4 | ||||
| ? | VP9587 | FINGER | 1 | ||||
| ? | VS9255 | BASE | 1 | ||||
| ? | VM0251 | FINGER/TIPS AND SHUNT | 1 | ||||
| ? | VM0240 | SPRING | 1 | ||||
| ? | VS6662 | FLAT WASHER - #10 | 4 | ||||
| ? | SF2755 | NUT - #10 - 32NF | 4 | ||||
| ? | VS9223 | SUPPORT | 1 | ||||
| ? | VM0226 | CONTACT | 4 | ||||
| ? | VS6662 | FLAT WASHER - #10 | 8 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 8 | ||||
| ? | SF2755 | NUT - #10 - 32NF | 8 | ||||
| ? | VJ9235 | MACHINE SCREW - #10 - 32NF X 7/8" | 4 | ||||
| ? | VS9284 | MAGNET FRAME | 1 | ||||
| ? | VM0227 | CONTACT | 4 | ||||
| ? | VJ9163 | FLAT WASHER | 1 | ||||
| ? | VJ9159 | MACHINE SCREW / WASHERS - #10 - 32NF X 3/8" | 2 | ||||
| ? | H2643 | LOCKWASHER - #10 | 2 | ||||
| ? | VP9593 | CAPSCREW / WASHERS | 2 | ||||
| ? | VJ9162 | CAPSCREW / WASHERS - 1/4" - 20NC X 3/4" | 2 | ||||
| ? | C5747 | CAPSCREW - 5/16" - 18NC X 3/4" | 1 | ||||
| ? | VM0278 | COIL, OPERATING | 1 |
