| Наименование | Страница | Код страницы |
|---|---|---|
| REAR SUSPENSION ASSEMBLY 58D-50-00060 | 140 | 56173 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58D-50-00130 | REAR SUSPENSION W/BEARINGS | 1 | ||||
| ? | 58D-50-00060 | • REAR SUSPENSION ASSEMBLY (1) (SEE INDEX) | 1 | 56173 | |||
| ? | VN9350 | • RING, RETAINER (2) | 4 | ||||
| ? | PC0829 | • BEARING, SPHERICAL (2) | 2 | ||||
| ? | EC4160 | SPACER (2) | 4 | ||||
| ? | EK1327 | PIN (2) | 2 | ||||
| ? | EM8121 | SHOULDER BOLT - 5/8" - 11NC X 7.88" (2) | 1 | ||||
| ? | WA0361 | FLAT WASHER - 5/8" (2) | 2 | ||||
| ? | VN9952 | LOCKNUT - 5/8" - 11NC (2) | 2 | ||||
| ? | EM8115 | SHOULDER BOLT - 5/8" - 11NC X 7.41" (2) | 1 | ||||
| ? | 56250-36191 | GUARD | 1 | ||||
| ? | PC1006 | CLAMP, WORM DRIVE | 1 | ||||
| ? | NOTE: (1) NOT INCLUDED AS AN ASSEMBLY. | ||||||
| ? | ORDER NEXT HIGHER LEVEL. | ||||||
| ? | 58D-MP-AK050 | (2) INCLUDED IN 58D-MP-AK050 PAN HARD ROD / | |||||
| ? | REAR SUSPENSION PIN KIT. | ||||||
| ? | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
