| Наименование | Страница | Код страницы |
|---|---|---|
| RIM ASSEMBLY | 112 | 56033 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XB5754 | RIM ASSEMBLY (SEE FIG 56033) | 2 | 56033 | |||
| ? | XB6249 | PLATE, BENT | 1 | ||||
| ? | C1547 | FLAT WASHER - 3/8" | 2 | ||||
| ? | C1601 | CAPSCREW - 3/8" - 16NC X 3/4" | 2 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 2 | ||||
| ? | XB4875 | ADAPTER, RING ASSEMBLY (OUTER) | 1 | ||||
| ? | XB4874 | • RING, ADAPTER | 1 | ||||
| ? | XB4708 | • STUD W/ HEAD (1) | 71 | ||||
| ? | WB3205 | NUT - 1" - 8NC (2) | 142 | ||||
| ? | WB1134 | NUT - 1 1/4" - 7NC | 52 | ||||
| ? | PC2396 | CONNECTOR, SWIVEL NUT | 2 | ||||
| ? | PC0580 | SPUD, COLLIE | 2 | ||||
| ? | PC1452 | EXTENSION, FLEXIBLE | 2 | ||||
| ? | PC0583 | HOUSING, CORE | 3 | ||||
| ? | PC3113 | EXTENSION, FLEXIBLE (OUTER) | 1 | ||||
| ? | XB8292 | PLATE, BENT | 1 | ||||
| ? | XB8491 | COVER | 1 | ||||
| ? | TG5720 | CAPSCREW - 3/8" - 16NC X 1" | 3 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 3 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 3 | ||||
| ? | 58D-MH-AK030 | NOTE: (1) INCLUDED IN 58D-MH-AK030 WHEEL STUD KIT. | |||||
| ? | 58D-MH-AK020 | (2) INCLUDED IN 58D-MH-AK020 LUG NUT KIT. | |||||
| ? | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
