| Наименование | Страница | Код страницы |
|---|---|---|
| RIM ASSEMBLY | 112 | 56033 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XB8292 | PLATE, BENT | 1 | ||||
| ? | XB5754 | RIM ASSEMBLY (SEE FIG 56033) | 1 | 56033 | |||
| ? | PC0580 | SPUD, COLLIE | 1 | ||||
| ? | PC2396 | CONNECTOR, SWIVEL NUT | 1 | ||||
| ? | C1547 | FLAT WASHER - 3/8" | 1 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 1 | ||||
| ? | C1601 | CAPSCREW - 3/8" - 16NC X 3/4" | 1 | ||||
| ? | PC0583 | HOUSING, CORE | 1 | ||||
| ? | WA2670 | CAP, VALVE | 1 | ||||
| ? | PC2380 | EXTENSION, FLEXIBLE | 1 | ||||
| ? | XB4708 | STUD W/ HEAD (1) | 71 | ||||
| ? | WB3205 | NUT - 1" - 8NC (2) | 71 | ||||
| ? | 58D-MH-AK030 | NOTE: (1) INCLUDED IN 58D-MH-AK030 WHEEL STUD KIT. | |||||
| ? | 58D-MH-AK020 | (2) INCLUDED IN 58D-MH-AK020 LUG NUT KIT. | |||||
| ? | (QUANTITES SHOWN ARE FOR ONE SIDE ONLY.) |
