| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XA4284 | HUB CAP ASSEMBLY | 1 | ||||
| ? | XA4285 | • HANDLE | 2 | ||||
| ? | BF3864 | • LATCH | 4 | ||||
| ? | 58D-98-00140 | WHEEL HUB ASSEMBLY | 1 | ||||
| ? | 58D-98-02000 | TUBE, TORQUE | 1 | ||||
| ? | 58D-98-01980 | FRAME | 1 | ||||
| ? | EM5451 | STUD, THREADED - 1 1/4" - 7NC X 10 13/16" | 52 | ||||
| ? | 58D-98-00470 | STUD, KNURLED | 71 | ||||
| ? | TD8074 | ADHESIVE | |||||
| ? | VS7492 | GASKET, LIQUID | |||||
| ? | VS8999 | SEALANT | |||||
| ? | 58D-98-02080 | SEALANT, THREADLOCKER | |||||
| ? | BF1484 | CAPSCREW - 1" - 14NF X 5 1/2" | 47 | ||||
| ? | XA4287 | FLAT WASHER - 1 1/16" | 47 | ||||
| ? | VS8408 | PIN, LOCATING | 1 | ||||
| ? | 58D-98-02020 | PLATE, CLAMP | 18 | ||||
| ? | 58D-98-00360 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 36 | ||||
| ? | VE4243 | WASHER, CONCAVE - 1/2" | 144 | ||||
| ? | 58D-98-00400 | CAPSCREW - 1/2" - 13NC X 2 1/4" | 16 | ||||
| ? | VE5185 | FLAT WASHER - 1/2" | 16 | ||||
| ? | 58D-98-00330 | RING, SEAL (1) | 1 | ||||
| ? | VE2316 | PLUG, PIPE | 16 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | 58D-98-02090 | WHEEL MOTOR (LESS TRANSMISSION) | 1 | ||||
| ? | 58D-WM-AK010 | NOTE: (1) INCLUDED IN 58D-WM-AK010 WHEEL MOTOR | |||||
| ? | OVERHAUL KIT. |
