| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE3530 | POSITION SENSOR INTERLOCK | 1 | ||||
| ? | XA4230 | • BOX | 1 | ||||
| ? | BF3174 | • COVER | 1 | ||||
| ? | VE1142 | • PIN | 2 | ||||
| ? | VE3616 | • INNER ARM ASSEMBLY | 1 | ||||
| ? | VE0735 | • SPRING | 1 | ||||
| ? | VE5751 | • MACHINE SCREW - #4 - 40NC X 5/8" | 1 | ||||
| ? | VE4908 | • LOCKWASHER - #4 | 1 | ||||
| ? | VE4909 | • NUT - #4 - 40NC | 1 | ||||
| ? | VE1143 | • SPRING | 1 | ||||
| ? | VE4405 | • STUD ASSEMBLY | 1 | ||||
| ? | VE4406 | • STUD ASSEMBLY | 1 | ||||
| ? | VE5752 | • STUD, TAPPED | 1 | ||||
| ? | VE5753 | • MACHINE SCREW - #4 - 40NC X 1/4" | 1 | ||||
| ? | VE4908 | • LOCKWASHER - #4 | 1 | ||||
| ? | VE4907 | • FLAT WASHER - #4 | 1 | ||||
| ? | BF0020 | • MACHINE SCREW - #6 - 32NC X 5/8" | 5 | ||||
| ? | VE5755 | • LOCKWASHER - #6 | 5 | ||||
| ? | VE5756 | • FLAT WASHER - #6 (NARROW) | 5 | ||||
| ? | VE5757 | • OUTER ARM ASSEMBLY | 1 | ||||
| ? | VE4602 | • NUT - #10 - 32NF | 3 | ||||
| ? | VE4601 | • LOCKWASHER - #10 | 3 | ||||
| ? | VE4600 | • FLAT WASHER - #10 (NARROW) | 3 |
