Содержание Dump Trucks Komatsu AFE69-C 730E-8 S/N A40009 - A40013 WESTMORELAND COAL(AFE69-C)
DOORS AND COVERS 1/2(654 : 43673)
Номер на схеме Каталожный номер Название Количество Детали
? 58D-98-01190 COVER ASSEMBLY 1
? 58D-98-01160 COVER ASSEMBLY, REAR 2
? 58D-98-01900 GASKET (21.43") 4
? 58D-98-01910 GASKET (11.43") 4
? GE1771 HINGE 12
? GE1242 LATCH & KEEPER 2
? 58D-98-01110 DOOR ASSEMBLY 1
? 58D-98-01880 GASKET (45.92") 2
? 58D-98-01890 GASKET (19.57") 2
? XA5307 BRACKET, DOOR 3
? XA5306 BRACKET, DOOR 3
? 58D-98-01140 ROD, DOOR STOP 3
? 58D-98-01020 DOOR ASSEMBLY, LH 1
? 58D-98-01030 GASKET (63.62") 1
? 58D-98-01040 GASKET (1" X 1" X 2") 1
? 58D-98-01050 DOOR ASSEMBLY 1
? 58D-98-01060 DOOR ASSEMBLY, RH 1
? 58D-98-01490 GASKET (38.32") 2
? 58D-98-01850 GASKET (16.74") 2
? 58D-98-01090 DOOR ASSEMBLY, RH 1
? 58D-98-01860 GASKET (42.32") 2
? 58D-98-01870 GASKET (27.72") 2
? 58D-98-01200 COVER ASSEMBLY 1
? GE0265 GASKET (7/8" X 1/4")
? 58D-98-01220 COVER 1
? VJ2672 CEMENT

Dump Trucks Komatsu / AFE69-C 730E-8 S/N A40009 - A40013 WESTMORELAND COAL(AFE69-C) / DOORS AND COVERS 1/2(654 : 43673)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
