| Наименование | Страница | Код страницы |
|---|---|---|
| POSITION SENSOR INTERLOCK VE3530 | 670 | 64035 |
| CONTACTOR - GF & GFR VE1317 | 668 | 64069 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB6137 | CONTACTOR ASSEMBLY | 1 | ||||
| ? | VE3530 | • POSITION SENSOR INTERLOCK (SEE INDEX) | 1 | 64035 | |||
| ? | VE1317 | • CONTACTOR - GF & GFR (SEE INDEX) | 1 | 64069 | |||
| ? | GE0174 | SWITCH, TOGGLE | 1 | ||||
| ? | GE0176 | SWITCH, TOGGLE | 2 | ||||
| ? | 58D-98-01810 | CAPSCREW - 5/16" - 18NC X 4" | 24 | ||||
| ? | 58D-98-01790 | CAPSCREW - 5/16" - 18NC X 3 1/4" | 36 | ||||
| ? | 58D-98-01800 | FLAT WASHER - 11/16" | |||||
| ? | VE4687 | LOCKWASHER - 3/8" | 40 | ||||
| ? | VE4700 | NUT - 3/8" - 16NC | 48 | ||||
| ? | BF0543 | CAPSCREW - 5/16" - 18NC X 2 1/2" | 18 | ||||
| ? | 58D-98-00910 | CAPSCREW - 3/8" - 16NC X 2 1/4" | 13 | ||||
| ? | VE4698 | NUT - 1/2" - 13NC | 36 | ||||
| ? | VE4519 | FLAT WASHER - 1/2" | 48 | ||||
| ? | VE4518 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 32 | ||||
| ? | 58D-98-00860 | STUD | 36 | ||||
| ? | 58D-98-01010 | CAPSCREW - 5/16" - 18NC X 2 3/4" | 10 | ||||
| ? | VE3918 | FLAT WASHER - 3/8" | |||||
| ? | 58D-98-00830 | CAPSCREW - 3/8" - 16NC X 5 1/2" | |||||
| ? | 58D-98-00900 | WASHER - 3/4" | 36 | ||||
| ? | VE4696 | LOCKWASHER - 5/16" | 54 | ||||
| ? | VE5013 | NUT - 5/16" - 18NC | 70 | ||||
| ? | (SEE THE PROCEDING PAGES FOR VIEWS A-A THROUGH F-F.) |
