Содержание Dump Trucks Komatsu AFE69-C 730E-8 S/N A40009 - A40013 WESTMORELAND COAL(AFE69-C)
CONTROL CABINET 2/6(644 : 43668)
Номер на схеме Каталожный номер Название Количество Детали
? 58D-98-01750 PANEL, IGBT CHOPPER MODULE 4
? 58D-98-00530 PANEL, POSITIVE IGBT MODULE 6
? 58D-98-00540 PANEL, NEGATIVE IGBT MODULE 6
? 58D-98-00730 BAR, BUS 2
? 58D-98-00680 BAR, BUS 4
? XA3143 STUD 24
? 58D-98-00650 BAR, BUS 4
? PB3348 INSULATOR 8
? XA4876 CAPACITOR, FILTER 6
? XA5273 SPACER 12
? VE4687 LOCKWASHER - 3/8" 40
? 58D-98-00840 FLAT WASHER - 3/8" 37
? VE4500 CAPSCREW - 3/8" - 16NC X 1 3/4" 4
? 58D-98-00660 BAR, BUS 1
? VE4518 CAPSCREW - 1/2" - 13NC X 1 1/2" 32
? GE0579 STUD 8
? 58D-98-00570 SENSOR, AC-DC 8
? VE4600 FLAT WASHER - #10 72
? VE4601 LOCKWASHER - #10 72
? VE4602 NUT - #10 - 32NF 72
? 58D-98-00690 BAR, BUS 1
? 58D-98-00760 CAPACITOR 1
? VE4693 LOCKWASHER - 5/16" 54
? VE5013 NUT - 5/16" - 18NC 70
? VE4699 LOCKWASHER - 1/2" 62
? VE4698 NUT - 1/2" - 13NC 36
? VE4519 FLAT WASHER - 1/2" 48
? 58D-98-00670 BAR, BUS 6
? 58D-98-00920 SEAL, TRIM
? 58D-98-00750 BAR, BUS 1
? 58D-98-01780 BAR, BUS 1
