| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XA5559 | SHROUD, FAN | 1 | ||||
| ? | XA5571 | RING, FAN | 1 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 17 | ||||
| ? | C1547 | FLAT WASHER - 3/8" | 34 | ||||
| ? | VE8559 | LOCKWASHER - 3/8" | 18 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 20 | ||||
| ? | XA3766 | NIPPLE | 2 | ||||
| ? | XA3793 | FITTING | 1 | ||||
| ? | VE8326 | REDUCER | 2 | ||||
| ? | BF4464 | NIPPLE | 2 | ||||
| ? | XA5363 | U-BOLT ASSEMBLY | 2 | ||||
| ? | E3735 | FLAT WASHER - 5/16" | 10 | ||||
| ? | C1520 | NUT - 5/16" - 18NC | 4 | ||||
| ? | XA3767 | CLAMP, HOSE | 2 | ||||
| ? | XA5573 | HOSE | 1 | ||||
| ? | XA3794 | CLAMP, HOSE | 2 | ||||
| ? | VE4441 | ELBOW | 1 | ||||
| ? | VE4005 | CAPSCREW - 3/8" - 16NC X 3/4" | 12 | ||||
| ? | TD0791 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 3 | ||||
| ? | VE1223 | CLIP - 1/2" X 1 1/2" | 5 | ||||
| ? | VE4013 | FITTING | 4 | ||||
| ? | VE4011 | FITTING | 4 | ||||
| ? | VE4443 | HOSE | 2 | ||||
| ? | C5747 | CAPSCREW - 5/16" - 18NC X 3/4" | 4 | ||||
| ? | VN9752 | LOCKNUT, NYLON - 5/16" - 18NC | 2 |
