| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58D-40-00020 | TUBE, TIE ROD | 1 | ||||
| ? | 58D-40-00040 | END, ROD - RH | 1 | ||||
| ? | 58D-40-00050 | END, ROD - LH | 1 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 12 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 12 | ||||
| ? | EK9254 | RETAINER, ANTI-ROTATION (1) | 2 | ||||
| ? | PC1680 | BEARING, SPHERICAL (STANDARD) | 2 | ||||
| ? | VN9179 | CAPSCREW - 3/4" - 10NC X 6" | 8 | ||||
| ? | WA0362 | FLAT WASHER - 3/4" (HARDENED) | 16 | ||||
| ? | VL2993 | LOCKNUT - 3/4" - 10NC | 8 | ||||
| ? | 58D-40-00000 | CLAMP, ROD END | 4 | ||||
| ? | 58D-MP-AK010 | NOTE: (1) INCLUDED IN 58D-MP-AK010 STEERING CYLINDER | |||||
| ? | AND TIE ROD PIN KIT. |
