| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | CD9707 | CLAMP, WORM DRIVE | 4 | ||||
| ? | XB5709 | HOSE | 1 | ||||
| ? | XB5708 | HOSE | 1 | ||||
| ? | TF6924 | CLAMP, VINYL - 1 3/4" | 4 | ||||
| ? | TC1233 | NUT - 3/8" - 16NC | 2 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 4 | ||||
| ? | WA4726 | FLAT WASHER - 3/8" (HARDENED) | 2 | ||||
| ? | EL6213 | FITTING, ELBOW | 1 | ||||
| ? | VC8762 | CAPSCREW - 3/8" - 16NC X 1 1/2" | 4 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 4 | ||||
| ? | EL4792 | GASKET | 1 | ||||
| ? | EH7753 | HOSE | 1 | ||||
| ? | WB1047 | CLAMP, T-BOLT | 4 | ||||
| ? | XB5636 | TUBE, COOLANT | 1 | ||||
| ? | TR3782 | CAPSCREW - 5/16" - 18NC X 1 1/4" | 1 | ||||
| ? | C1538 | LOCKWASHER - 5/16" | 1 | ||||
| ? | TV0177 | FLAT WASHER - 5/16" | 3 | ||||
| ? | WA1601 | END, ROD | 2 | ||||
| ? | SF4358 | JAM NUT - 5/16" - 24NC | 2 | ||||
| ? | EG7531 | ROD, THREADED | 1 | ||||
| ? | C1639 | CAPSCREW - 5/16" - 18NC X 2" | 1 | ||||
| ? | VN9752 | LOCKNUT, NYLON - 5/16" - 18NC | 1 | ||||
| ? | PC2137 | CLAMP, BAND | 1 | ||||
| ? | ED0020 | HOSE, COOLANT | 1 | ||||
| ? | WB1051 | CLAMP, T-BOLT | 3 | ||||
| ? | XC2602 | TUBE, COOLANT | 1 | ||||
| ? | PC2143 | VALVE, BALL | 1 | ||||
| ? | R2028 | PLUG, PIPE | 3 | ||||
| ? | EH3176 | PLATE, BENT | 1 | ||||
| ? | XC2613 | BRACKET | 1 | ||||
| ? | TC1234 | CAPSCREW - 3/8" - 16NC X 3/4" | 2 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 2 | ||||
| ? | MM0606 | CAPSCREW - M10 X 1.50 X 30 | 2 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 2 | ||||
| ? | MM0713 | FLAT WASHER - M10 (HARDENED) | 2 |
