| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-06-10020 | RELAY | 3 | ||||
| ? | SG3408 | NUT - #10 - 24NC | 6 | ||||
| ? | VC5344 | FLAT WASHER - #10 | 3 | ||||
| ? | 58D-06-00242 | HARNESS, LADDER | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 8 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 12 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 10 | ||||
| ? | 58F-80-05040 | BOX, LADDER OVERRIDE BUTTON | 1 | ||||
| ? | 58E-06-13190 | SWITCH, PULL/PUSH | 1 | ||||
| ? | 58F-80-05540 | COVER, LADDER OVERRIDE BUTTON | 1 | ||||
| ? | MM0581 | CAPSCREW - M6 X 1.00 X 16 | 3 | ||||
| ? | MM0711 | FLAT WASHER - M6 | 5 | ||||
| ? | VP4693 | GROMMET, RUBBER | 1 | ||||
| ? | 58E-06-08400 | ALARM, LADDER | 1 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 2 | ||||
| ? | MM0176 | NUT - M6 X 1.00 | 2 | ||||
| ? | XB5184 | SEAT | 2 | ||||
| ? | VY0876 | GROMMET | 1 | ||||
| ? | WB1304 | CLAMP, CUSHIONED - 9/16" | 2 | ||||
| ? | 07020-00001 | FITTING | 2 | ||||
| ? | XC3297 | PIN | 2 | ||||
| ? | 07145-00050 | SEAL | 4 | ||||
| ? | 21W-70-41741 | BUSHING | 2 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 2 | ||||
| ? | 08193-21012 | CLIP | 2 | ||||
| ? | 56B-06-15610 | SWITCH, PROXIMITY | 2 | ||||
| ? | WB3524 | SCREW - #12 - 14NC X 3/4" | 4 | ||||
| ? | EM9230 | PLATE, COVER | 4 | ||||
| ? | XC3533 | PLATE, MOUNTING | 4 | ||||
| ? | XC3532 | SCREW - #12 - 14NC X 3/4" | 4 | ||||
| ? | 58B-54-04840 | BUMPER | 2 | ||||
| ? | 58B-09-00200 | CAPSCREW, SOCKET HEAD - M6 X 1.00 X 25 | 4 |
