| Наименование | Страница | Код страницы |
|---|---|---|
| SMART RIM ASSEMBLY - REAR OUTER | 138 | 43701 |
| RIM ASSEMBLY, TAPER LOCK | 136 | 56033 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58B-30-00500 | RIM - 63" X 44" (SEE FIG 43701) | 1 | 43701 | |||
| ? | WB1303 | CLAMP, CUSHIONED - 3/4" | 2 | ||||
| ? | C1601 | CAPSCREW - 3/8" - 16NC X 3/4" | 2 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 2 | ||||
| ? | C1547 | FLAT WASHER - 3/8" | 2 | ||||
| ? | 58B-30-00380 | ADAPTER RING ASSEMBLY (OUTER) | 2 | ||||
| ? | 58B-30-00370 | • RING, ADAPTER | 2 | ||||
| ? | 58B-30-00340 | • STUD W/ HEAD | 56 | ||||
| ? | WB1134 | NUT - 1 1/4" - 7NC | 225 | ||||
| ? | GE0534 | STUD (SPECIAL) | 54 | ||||
| ? | PC0579 | CONNECTOR, SWIVEL NUT | 2 | ||||
| ? | PC0580 | SPUD, COLLIE | 2 | ||||
| ? | 58B-30-00410 | EXTENSION, FLEXIBLE | 1 | ||||
| ? | PC0583 | HOUSING, CORE | 2 | ||||
| ? | EL1893 | PLATE, BENT | 1 | ||||
| ? | 58B-30-00280 | EXTENSION, FLEXIBLE | 1 | ||||
| ? | 58B-30-00420 | EXTENSION, FLEXIBLE (OUTER) | 1 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 4 | ||||
| ? | 58B-30-00190 | COVER | 1 | ||||
| ? | TC1234 | CAPSCREW - 3/8" - 16NC X 3/4" | 4 | ||||
| ? | 58B-30-00550 | RIM - 63" X 44" (SEE FIG 56033) | 1 | 56033 | |||
| ? | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
