| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XA5285 | RESISTOR ASSEMBLY | 1 | ||||
| ? | 58F-43-00250 | • RESISTOR - 50W, 50 OHM | 1 | ||||
| ? | SF2755 | NUT - #10 - 32NF | 6 | ||||
| ? | VE4601 | LOCKWASHER - #10 | 6 | ||||
| ? | VE4655 | FLAT WASHER - #10 | 6 | ||||
| ? | XA4327 | RESISTOR, CDI | 2 | ||||
| ? | XA3593 | SUPPORT | 1 | ||||
| ? | VE4700 | NUT - 3/8" - 16NC | 2 | ||||
| ? | VE4687 | LOCKWASHER - 3/8" | 2 | ||||
| ? | VE4515 | FLAT WASHER - 3/8" | 2 | ||||
| ? | GE1401 | BUS BAR | 1 | ||||
| ? | GE1402 | BUS BAR | 1 | ||||
| ? | XA4249 | BUS BAR | 5 | ||||
| ? | 58F-43-00430 | BUS BAR | 4 | ||||
| ? | XA4250 | BUS BAR | 1 | ||||
| ? | VE4698 | NUT - 1/2" - 13NC | 25 | ||||
| ? | VE4699 | LOCKWASHER - 1/2" | 25 | ||||
| ? | VE4519 | FLAT WASHER - 1/2" (NARROW) | 18 | ||||
| ? | 58D-98-00400 | CAPSCREW - 1/2" - 13NC X 2 1/4" | 10 | ||||
| ? | VE3030 | FLAT WASHER - 1 1/4" OD | 16 | ||||
| ? | VE3918 | WASHER | 20 | ||||
| ? | WA0720 | FLAT WASHER - 3/8" (HARDENED) | 20 | ||||
| ? | XA4255 | CAPSCREW - 3/8" - 16NC X 2" | 18 | ||||
| ? | VE4640 | CAPSCREW - 3/8" - 16NC X 1 1/2" | 2 | ||||
| ? | GE1415 | BRACKET ASSEMBLY | 4 | ||||
| ? | VE5013 | NUT - 5/16" - 18NC | 8 | ||||
| ? | VE4696 | LOCKWASHER - 5/16" | 8 | ||||
| ? | VE4343 | FLAT WASHER - 5/16" | 8 | ||||
| ? | PB3348 | INSULATOR | 8 | ||||
| ? | GE0579 | STUD | 8 | ||||
| ? | GE1396 | BUS BAR | 1 | ||||
| ? | VE5061 | CAPSCREW - 1/2" - 13NC X 2 1/2" | 7 |
