Номер на схеме	Каталожный номер	Название	Количество
?		HOUSING (1)	1
?	58B-98-01210	PISTON	1
?	EC1015	GAS VALVE ASSEMBLY (3)	1
?	TD7179	• CORE, VALVE	1
?	EC1447	• BODY, VALVE	1
?	TL3995	• O-RING (2)	1
?	58B-98-01270	GUARD, GAS VALVE	1
?	XA5153	GAS VALVE ASSEMBLY	1
?	58F-60-40180	SPACER	1
?	58B-98-01260	HEAD, OIL END	1
?	58B-60-20140	SEAL (2)	2
?	58B-60-20150	O-RING (2)	2
?	58B-98-01350	PLUG, O-RING (2)	2
?	58B-98-01290	CAPSCREW, SOCKET HEAD - 3/8" - 16NC	2
?	58B-98-01250	HEAD, GAS END	1
?	58B-98-01360	PLATE, ASME	1
?	58B-98-01370	PLATE, AS1210	1
?	58B-60-40100	DECAL	3
?	58B-98-01330	DECAL, USA	1
?	58B-98-01190	SEAL, PISTON - "U" (2)	2
?	58B-98-01310	RING, BACKUP (2)	2
?	58B-98-01300	BEARING, PISTON (2)	2
?	58B-98-01280	RING, BACKUP (2)	2
?	58B-98-01200	SEAL, PISTON - "T" (2)	1
?		NOTE: (1) NOT SERVICED SEPARATELY.
?	58B-98-01320	(2) INCLUDED IN 58B-98-01320 ACCUMULATOR OVERHAUL SEAL KIT.
?		(3) IF GAS VALVE ASSEMBLY IS REMOVED
?		USE O-RING PLUG - 58B-98-01340.
