| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB6770 | COUPLING, MALE QUICK DISCONNECT | 2 | ||||
| ? | WB0508 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | VM0315 | PLUG | 2 | ||||
| ? | VM0319 | PLUG | 3 | ||||
| ? | WB0586 | FITTING, STRAIGHT | 1 | ||||
| ? | VM0317 | PLUG | 2 | ||||
| ? | WB0499 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | VM0313 | PLUG | 6 | ||||
| ? | WB0584 | FITTING, STRAIGHT | 4 | ||||
| ? | VM0314 | PLUG | 2 | ||||
| ? | 603517C1 | PLUG, FLANGE | 1 | ||||
| ? | TF8077 | CLAMP, SPLIT FLANGE | 2 | ||||
| ? | TF3237 | CLAMP, SPLIT FLANGE - 1 1/4" | 10 | ||||
| ? | TR4090 | CAPSCREW - 7/16" - 14NC X 1 1/2" | 20 | ||||
| ? | TD0795 | LOCKWASHER - 7/16" | 20 | ||||
| ? | VG9096 | O-RING | 6 | ||||
| ? | WA5630 | CLAMP, SPLIT FLANGE - 1 1/4" | 2 | ||||
| ? | TV1918 | CAPSCREW - 1/2" - 13NC X 1 3/4" | 4 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 4 | ||||
| ? | TD0791 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 4 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 4 | ||||
| ? | VG9097 | O-RING | 1 |
