| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB0599 | FITTING, STRAIGHT | 1 | ||||
| ? | TV1918 | CAPSCREW - 1/2" - 13NC X 1 3/4" | 12 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 16 | ||||
| ? | VH6718 | CLAMP, SPLIT FLANGE - 2 1/2" | 2 | ||||
| ? | WA0232 | O-RING | 1 | ||||
| ? | 58B-09-00510 | CAPSCREW - 5/8" - 11NC X 2 1/4" | 4 | ||||
| ? | VC1390 | LOCKWASHER - 5/8" | 4 | ||||
| ? | WA5629 | CLAMP, SPLIT FLANGE | 2 | ||||
| ? | VG9095 | O-RING | 3 | ||||
| ? | WB0499 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | 58B-60-10360 | HOSE | 1 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 4 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 1 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 1 | ||||
| ? | HA7687 | HOSE | 1 | ||||
| ? | WA5630 | CLAMP, SPLIT FLANGE - 1 1/4" | 4 | ||||
| ? | HA8218 | HOSE | 1 | ||||
| ? | 58B-60-01990 | HOSE | 1 | ||||
| ? | WB0988 | CLAMP, HEAVY DUTY | 2 | ||||
| ? | HA8703 | HOSE | 1 | ||||
| ? | C1614 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 4 | ||||
| ? | WA4728 | FLAT WASHER - 1/2" | 4 | ||||
| ? | C1523 | NUT - 1/2" - 13NC | 4 | ||||
| ? | WB1055 | CLAMP, VINYL - 3 1/2" ID | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 1 | ||||
| ? | WB1305 | CLAMP, CUSHIONED - 1 1/2" | 2 | ||||
| ? | VG9096 | O-RING | 2 |
