| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58B-60-20210 | HOSE | 1 | ||||
| ? | HA7919 | HOSE | 1 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 6 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 6 | ||||
| ? | WB1305 | CLAMP, CUSHIONED - 1 1/2" | 6 | ||||
| ? | WB3094 | CLAMP, CUSHIONED - 1 3/4" | 2 | ||||
| ? | VG9096 | O-RING | 2 | ||||
| ? | TF3237 | CLAMP, SPLIT FLANGE - 1 1/4" | 4 | ||||
| ? | TR4090 | CAPSCREW - 7/16" - 14NC X 1 1/2" | 8 | ||||
| ? | TD0795 | LOCKWASHER - 7/16" | 8 | ||||
| ? | 58B-60-00170 | HOSE | 1 | ||||
| ? | 58B-60-00160 | HOSE | 1 | ||||
| ? | WA4709 | CLAMP, HYDRA ZORB - 1 1/4" | 2 | ||||
| ? | EK2624 | TUBE | 1 | ||||
| ? | EK2623 | TUBE | 1 | ||||
| ? | 58B-60-10480 | HOSE | 1 | ||||
| ? | WB1306 | CLAMP, CUSHIONED - 2" | 1 | ||||
| ? | 58B-60-10360 | HOSE | 1 | ||||
| ? | HA8703 | HOSE | 1 | ||||
| ? | 58B-60-10440 | HOSE | 1 | ||||
| ? | 58B-60-10430 | HOSE | 1 | ||||
| ? | TV1918 | CAPSCREW - 1/2" - 13NC X 1 3/4" | 4 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 4 | ||||
| ? | WA5630 | CLAMP, SPLIT FLANGE - 1 1/4" | 2 | ||||
| ? | TY8375 | SPACER | 1 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 3 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 3 | ||||
| ? | EM6944 | SPACER | 1 |
