| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 656658C1 | PLUG, FLANGE | 1 | ||||
| ? | VG9096 | O-RING | 2 | ||||
| ? | TF3237 | CLAMP, SPLIT FLANGE - 1 1/4" | 4 | ||||
| ? | C1609 | CAPSCREW - 7/16" - 14NC X 1 1/2" | 8 | ||||
| ? | C5775 | LOCKWASHER - 7/16" | 8 | ||||
| ? | VM0317 | PLUG | 2 | ||||
| ? | HA7687 | HOSE | 1 | ||||
| ? | VG9097 | O-RING | 1 | ||||
| ? | TF8077 | CLAMP, SPLIT FLANGE | 2 | ||||
| ? | C1603 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 4 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 4 | ||||
| ? | VM0314 | PLUG | 2 | ||||
| ? | 58B-60-10480 | HOSE | 1 | ||||
| ? | HA8218 | HOSE | 1 | ||||
| ? | WA0232 | O-RING | 3 | ||||
| ? | VH6718 | CLAMP, SPLIT FLANGE - 2 1/2" | 6 | ||||
| ? | C1623 | CAPSCREW - 1/2" - 13NC X 3 3/4" | 4 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 12 | ||||
| ? | HA7899 | HOSE | 1 | ||||
| ? | WA0237 | O-RING | 2 | ||||
| ? | VL9963 | CLAMP, SPLIT FLANGE - 3" | 4 | ||||
| ? | C1629 | CAPSCREW - 5/8" - 11NC X 1 3/4" | 4 | ||||
| ? | C1541 | LOCKWASHER - 5/8" | 12 | ||||
| ? | HA7707 | HOSE | 1 | ||||
| ? | WA0245 | O-RING | 1 | ||||
| ? | VN7716 | CLAMP, SPLIT FLANGE - 4" | 2 | ||||
| ? | C1630 | CAPSCREW - 5/8" - 11NC X 2" | 4 | ||||
| ? | VM0322 | PLUG | 1 | ||||
| ? | HA7704 | HOSE | 1 | ||||
| ? | C1615 | CAPSCREW - 1/2" - 13NC X 1 3/4" | 8 | ||||
| ? | HA7705 | HOSE | 1 | ||||
| ? | C1629 | CAPSCREW - 5/8" - 11NC X 1 3/4" | 4 | ||||
| ? | HA7705 | HOSE | 1 | ||||
| ? | WB0583 | FITTING, STRAIGHT | 1 | ||||
| ? | 58B-60-02060 | HOSE | 1 |
