Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
EK5654 |
TUBE, BENT - LH OUTER FRONT |
1 |
|
|
|
|
? |
VW7882 |
HOSE |
1 |
|
|
|
|
? |
WB1177 |
CLAMP, T-BOLT |
16 |
|
|
|
|
? |
EJ9919 |
BRACKET, MOUNTING |
1 |
|
|
|
|
? |
MM0462 |
FLAT WASHER - M12 |
2 |
|
|
|
|
? |
MM0616 |
CAPSCREW - M12 X 1.75 X 20 |
2 |
|
|
|
|
? |
WB1179 |
CLAMP, T-BOLT |
4 |
|
|
|
|
? |
EK5666 |
TUBE, BENT - LH MIDDLE FRONT |
1 |
|
|
|
|
? |
PB1597 |
ELBOW, RUBBER |
1 |
|
|
|
|
? |
EK5657 |
TUBE, BENT - LH INNER FRONT |
1 |
|
|
|
|
? |
TX6040 |
ELBOW, RUBBER - 45 DEG |
1 |
|
|
|
|
? |
TB1018 |
RAIN GUARD, RH |
2 |
|
|
|
|
? |
TB1017 |
RAIN GUARD |
1 |
|
|
|
|
? |
TR2961 |
CAPSCREW - 5/8" - 11NC X 1" |
8 |
|
|
|
|
? |
VC1390 |
LOCKWASHER - 5/8" |
8 |
|
|
|
|
? |
TR9082 |
FLAT WASHER - 5/8" |
8 |
|
|
|
|
? |
TB1019 |
RAIN GUARD, LH |
2 |
|
|
|
|
? |
TB1406 |
RAIN GUARD, FRONT |
1 |
|
|
|
|
? |
58B-02-00970 |
AIR CLEANER ASSEMBLY, SINGLE (SEE FIG 43407) |
1 |
|
43407 |
|
|
? |
EJ0609 |
SHEET |
1 |
|
|
|
|
? |
58F-02-00160 |
AIR CLEANER ASSEMBLY, DUAL (SEE FIG 68056) |
1 |
|
68056 |
|
|
? |
EH9685 |
TUBE, MIDDLE REAR - LH |
1 |
|
|
|
|
? |
58B-54-05110 |
TUBE, OUTER REAR - LH |
1 |
|
|
|
|
? |
XB9559 |
TUBE, LH INNER REAR |
1 |
|
|
|
|
? |
PC1115 |
HOSE, DOUBLE HUMP |
3 |
|
|
|
|
? |
EG8033 |
CLAMP, DOUBLE |
2 |
|
|
|
|
? |
TR4434 |
CAPSCREW - 3/8" - 16NC X 2" |
3 |
|
|
|
|
? |
HE5611 |
LOCKNUT - 3/8" - 16NC |
3 |
|
|
|
|
? |
WA4726 |
FLAT WASHER, HARDENED - 3/8" |
3 |
|
|
|
|
? |
WB1169 |
CLAMP, T-BOLT |
9 |
|
|
|
|
? |
EH9965 |
HOSE, TURBO CONNECTION |
3 |
|
|
|
|
? |
WB1178 |
CLAMP, T-BOLT |
4 |
|
|
|
