| Наименование | Страница | Код страницы |
|---|---|---|
| RADIATOR & SHROUD ASSEMBLY 58B-03-20010 | 064 | 62085 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58B-03-20010 | RADIATOR & SHROUD ASSEMBLY (SEE INDEX) | 1 | 62085 | |||
| ? | VN9107 | CAPSCREW - 1 1/2" - 6NC | 4 | ||||
| ? | WA0368 | FLAT WASHER, HARDENED - 1 1/2" | 4 | ||||
| ? | 58B-03-11020 | BRACKET - RH | 1 | ||||
| ? | 58B-03-11010 | BRACKET - LH | 1 | ||||
| ? | 58B-54-50830 | ARM, STABILIZER | 2 | ||||
| ? | 58E-09-00300 | CAPSCREW - M20 X 2.50 X 60 | 2 | ||||
| ? | VH8186 | LOCKNUT - 1" - 8NC | 4 | ||||
| ? | 58E-09-00200 | CAPSCREW - M16 X 2.00 X 35 | 8 | ||||
| ? | 58E-09-00510 | LOCKWASHER - M16 | 8 | ||||
| ? | 58E-09-00400 | FLAT WASHER, HARDENED - M16 | 8 | ||||
| ? | MM0091 | CAPSCREW - M20 X 2.50 X 80 | 8 | ||||
| ? | 01643-32060 | FLAT WASHER, HARDENED - M20 | 16 | ||||
| ? | MM0475 | LOCKWASHER - M20 | 8 | ||||
| ? | MM0182 | NUT - M20 X 2.50 | 8 | ||||
| ? | EF3378 | ROD, THREADED | 2 | ||||
| ? | PB6831 | ROD END | 2 | ||||
| ? | C1532 | NUT - 1" - 14UNS (SPECIAL) | 6 | ||||
| ? | E3909 | CAPSCREW - 1" - 8NC X 3 1/4" | 2 | ||||
| ? | ED9895 | FLAT WASHER - M24 (SPECIAL) | 4 | ||||
| ? | PC0780 | MOUNT, RUBBER | 2 | ||||
| ? | 58C-09-10020 | NUT - M20 X 2.50 | 2 | ||||
| ? | 58C-09-10070 | FLAT WASHER - M20 | 4 | ||||
| ? | 58D-90-00050 | BRACKET, STABILIZER | 2 | ||||
| ? | 58B-09-00310 | WASHER | 2 | ||||
| ? | TG6760 | MOUNT, RUBBER | 2 | ||||
| ? | TK6567 | WASHER | 2 | ||||
| ? | VF2856 | NUT - 1" | 2 |
